4. Valtra Guide operation

4.5 Adjust the steering settings

Procedure
Tap the Map screen
1.
Tap the Settings icon.
2.
Tap the Steering settings.
3.
To adjust the Steering settings, tap the icon.
4.
In a normal situation, Valtra Guide operates
correctly with the both sliders in the middle
position.
a) To adjust the wayline catch-up, drag the
slider for wayline catch-up.
When the slider is adjusted to the left, the
tractor steers toward the wayline
gradually. Use this when the implement is
connected to the rear linkage.
When the slider is adjusted to the right,
the tractor steers toward the wayline
quickly. Use this when the implement is
connected to the pick-up hitch.
b) To adjust the steering sensitivity, drag the
slider for steering sensitivity.
When the steering sensitivity is adjusted
to the left, the steering response is slow. Use this if the air pressure in the front tyies is very low
or the tractor wobbles along the wayline.
When the steering sensitivity is adjusted to the right, the steering response is quick. Use this if
the tractor follows the wayline too slowly.
c) Tap to accept or
96
AUTO
.
to discard the changes.
Fig. 87
Steering settings
(1)
1
WAYLINE CATCH-UP
STEERING SENSITIVITY
Fig. 88
Wayline catch-up
(1)
(2) Steering sensitivity
