R&G FP0222BK Fitting Instructions Manual

Fork protectors for ktm 790 adventure 2019
Hide thumbs

Advertisement

Table of Contents

FP0222BK
PAGE 1 OF 10
FITTING INSTRUCTIONS FOR FP0222BK FORK PROTECTORS
KTM 790 ADVENTURE 2019
Picture A
Picture B
.
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE
.
SOME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY
.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT
.
PLEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING
PLEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
.
MOUNTING TO THE BIKE
,
IN THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS
.
THESE RUBBER WASHERS CAN BE THROWN AWAY
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM
R&G Racing
Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire GU34 3AQ.
Tel: +44 (0)1420 89007 Fax +44 (0)1420 87301
www.rg-racing.com
Email:
info@rg-racing.com
