FP0228BK
PAGE 1 OF 9
FITTING INSTRUCTIONS FOR FP0228BK FORK PROTECTORS
BMW R1250R + R1250RS SPORT 2019-
Picture A
Picture B
.
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE
.
SOME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY
.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT
.
PLEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS OR HAVE
FITTED BY A QUALIFIED TECHNICIAN.
PLEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
.
MOUNTING TO THE BIKE
,
IN THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS
.
THESE RUBBER WASHERS CAN BE THROWN AWAY
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM
R&G Racing
Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire GU34 3AQ.
Tel: +44 (0)1420 89007 Fax +44 (0)1420 87301
www.rg-racing.com
Email:
info@rg-racing.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for R&G FP0228BK
Summary of Contents for R&G FP0228BK
- Page 1 FP0228BK PAGE 1 OF 9 FITTING INSTRUCTIONS FOR FP0228BK FORK PROTECTORS BMW R1250R + R1250RS SPORT 2019- Picture A Picture B THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE SOME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY...
-
Page 2: Exploded Assembly Diagram
FP0228BK PAGE 2 OF 9 TOOLS REQUIRED GENERAL TORQUE SETTINGS • 2 x 13mm Sockets M4 BOLT = 8Nm • 2 x Wrench or similar M5 BOLT = • Torque Wrench M6 BOLT = • Loctite or superglue M8 BOLT = 20Nm... -
Page 3: Fitting Instructions
FP0228BK PAGE 3 OF 9 FITTING INSTRUCTIONS • Fit one nut (item 5) and washer (item 6) on spindle-bar (item 2), engage the nut so the plastic insert of the nut is fully engaged and the bar protrudes by 1 to 2 threads. It is recommended to use a small amount of superglue or Loctite to fix this nut as this will aid when tightening the opposite side later. - Page 4 FP0228BK PAGE 4 OF 9 NOTICE DE MONTAGE POUR FP0228BK PROTECTIONS FOURCHE BMW R1250R + R1250RS SPORT 2019- Photo A Photo B E KIT CONTIENT LES ARTICLES EN PHOTO ET ETIQUETTES SUR LA PAGE LES PARTIES PRESENTÉES PEUVENT ETRE UNIQUEMENT REPRESENTATIVES POUR LA CLARTE DES INSTRUCTIONS E PAS ROCÉDER AU MONTAGE AVANT DE VOUS ÊTRES ASSURE QUE TOUTES LES PIECES SOIENT PRÉSENTES...
-
Page 5: Outils Requis
FP0228BK PAGE 5 OF 9 OUTILS REQUIS VALEURS DE SERRAGE • Clé à cliquet + douilles 2 x 13mm Sockets M4 BOULON = 8Nm • 2 x VClé à molette ou similaire M5 BOULON = • Clé dynamométrique M6 BOULON = •... -
Page 6: Notice De Montage
FP0228BK PAGE 6 OF 9 NOTICE DE MONTAGE • Placez un écrou (article 5) et une rondelle (article 6) sur l’axe (article 2), engagez l'écrou de sorte que l'insert en plastique de l'écrou soit complètement engagé et que l’axe dépasse de 1 à 2 filets. Il est recommandé... - Page 7 FP0228BK PAGE 7 OF 9 MONTAGEANLEITUNG FÜR FP0228BK GABELPROTEKTOREN BMW R1250R + R1250RS SPORT 2019- Abbildung A Abbildung B ALLE KIT-TEILE SIND UNTEN ABGEBILDET UND GEKENNZEICHNET. DIE ABGEBILDETEN TEILE DIENEN LEDIGLICH ZUR ERKLÄRUNG. ÜBERPRÜFEN SIE ZUERST, DASS ALLE TEILE VORHANDEN SIND.
- Page 8 FP0228BK PAGE 8 OF 9 SIE BENÖTIGEN FOLGENDES WERKZEUG ALLGEM. ANZUGSDREHMOMENT M4 SCHRAUBE = 8Nm • 2 x 13mm Steckschlüssel • 2 x Schraubenschlüssel M5 SCHRAUBE = • Drehmomentschlüssel M6 SCHRAUBE = • Loctite oder Sekundenkleber M8 SCHRAUBE = 20Nm...
- Page 9 FP0228BK PAGE 9 OF 9 MONTAGEANLEITUNG • Montieren Sie eine Mutter (Artikel 5) und eine Unterlegscheibe (Artikel 6) an der Verbindungsstange (Artikel 2). Die Mutter so anbringen, dass der Kunststoffeinsatz der Mutter komplett eingerastet ist und die Verbindungsstange mit 1 bis 2 Gewinden hervorsteht. Die Verwendung von etwas Sekundenkleber oder Loctite wird empfohlen, um die Mutter zu fixieren bzw.
