LP0335
FITTING INSTRUCTIONS FOR LP0335BK LICENCE PLATE BRACKET
TRIUMPH TIGER SPORT 660 2022-
This kit contains the items pictured and labelled over page.
Some parts may be shown for clarity of instructions only.
Do not proceed until you are sure all parts are present.
Please read all instructions before proceeding.
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
Please note that the way the kit is packed does not necessarily represent the way of
mounting to the bike.
In the event of rubber washers being used to hold components onto bolts,
these rubber washers can be thrown away.
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM
WWW.RG-RACING.COM
R&G
Unit
, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
1
Tel: +44 (0)
420 89007 Fax: +44 (0)
420 87301 www.rg-racing.com Email: info@rg-racing.com
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for R&G LP0335
Summary of Contents for R&G LP0335
- Page 1 Page 1 of 25 LP0335 FITTING INSTRUCTIONS FOR LP0335BK LICENCE PLATE BRACKET TRIUMPH TIGER SPORT 660 2022- This kit contains the items pictured and labelled over page. Some parts may be shown for clarity of instructions only. Do not proceed until you are sure all parts are present.
-
Page 2: Tools Required
Page 2 of 25 LP0335 TOOLS REQUIRED GENERAL TORQUE SETTINGS • Set metric allen keys. M4 BOLT = 8Nm Set of metric sockets and ratchet. • M5 BOLT = 12Nm Small flat head screwdriver. • Small amount of super glue. -
Page 3: Assembly Diagram
Page 3 of 25 LP0335 ASSEMBLY DIAGRAM 1 ASSEMBLY DIAGRAM 2 Must apply a Thread locking solution to 2 x Item 17 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) - Page 4 Page 4 of 25 LP0335 ASSEMBLY DIAGRAM 3 ASSEMBLY DIAGRAM 4 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) 420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 5 Page 5 of 25 LP0335 ASSEMBLY DIAGRAM 5 ASSEMBLY DIAGRAM 6 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) 420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 6 Page 6 of 25 LP0335 FITTING PICTURES Picture 1 Picture 2 Picture 3 Picture 4 Picture 5 Picture 6 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) 420 87301 www.rg-racing.com Email: info@rg-racing.com...
-
Page 7: Fitting Instructions
Page 7 of 25 LP0335 FITTING INSTRUCTIONS Removal of OEM license plate bracket Begin by removing the seat using the key slot as shown in Picture 1. • Remove the 2 x bolts shown in Picture 2 which are location underneath the seat. - Page 8 Page 8 of 25 LP0335 ISSUE 1 - 04/08/2021 - (AO) CONSUMER NOTICE The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design changes which do not diminish their performance or visual appeal and supplying them in such state shall conform to the order.
- Page 9 Page 9 of 25 LP0335 NOTICE DE MONTAGE POUR LP0335BK SUPPORT DE PLAQUE TRIUMPH TIGER SPORT 660 2022- E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES INSTRUCTIONS...
-
Page 10: Outils Requis
Page 10 of 25 LP0335 OUTILS REQUIS VALEURS DE SERRAGE • Clés Allen. M4 BOULON = 8Nm Clé à cliquet + douilles. • M5 BOULON = 12Nm Petit tournevis plat. • • Un peu de super glue. M6 BOULON = 15Nm •... -
Page 11: Schéma D'ensemble
Page 11 of 25 LP0335 ARTICLE 22 REFL3 (RÉFLECTEUR) SCHÉMA D’ENSEMBLE 1 SCHÉMA D’ENSEMBLE 2 Appliquer du frein filet sur les 2 x Article 17 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) - Page 12 Page 12 of 25 LP0335 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) 420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 13 Page 13 of 25 LP0335 SCHÉMA D’ENSEMBLE 3 SCHÉMA D’ENSEMBLE 4 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) 420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 14 Page 14 of 25 LP0335 SCHÉMA D’ENSEMBLE 5 SCHÉMA D’ENSEMBLE 6 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) 420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 15 Page 15 of 25 LP0335 PHOTOS DE MONTAGE Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 R&G Unit , Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0) 420 89007 Fax: +44 (0) 420 87301 www.rg-racing.com Email: info@rg-racing.com...
-
Page 16: Notice De Montage
Page 16 of 25 LP0335 NOTICE DE MONTAGE Enlever le support de plaque d’origine • Commencez par retirer le siège à l'aide de la fente de clé comme indiqué sur la photo 1. Retirez les 2 x boulons illustrés sur la photo 2 qui se trouvent sous le siège. - Page 17 Page 17 of 25 LP0335 Fixez le feu de plaque d'immatriculation fourni par R&G (article 6) et son enveloppe sur le • support de plaque d'immatriculation R&G (article 3), en vous assurant que les fils ont été enveloppés dans une gaine thermo rétractable (article 19) pour les protéger.
- Page 18 Page 18 of 25 LP0335 MONTAGEANLEITUNG FÜR LP0335BK KENNZEICHENHALTER TRIUMPH TIGER SPORT 660 2022- Alle Kit-Teile sind auf den nachfolgenden Seiten abgebildet und gekennzeichnet. Die abgebildeten Teile dienen lediglich zur Erklärung. Überprüfen Sie zuerst, dass alle Teile vorhanden sind. Lesen Sie die Montageanleitung komplett durch, bevor Sie anfangen.
- Page 19 Page 19 of 25 LP0335 SIE BENÖTIGEN FOLGENDES WERKZEUG ALLGEM. ANZUGDREHMOMENT Satz Inbusschlüssel M4 SCHRAUBE = 8Nm • Satz Steckschlüssel • M5 SCHRAUBE = 12Nm • Kl. Flachklingen-Schraubenzieher Kl. Menge Sekundenkleber • M6 SCHRAUBE = 15Nm Threadlocker/Schraubensicherung • M8 SCHRAUBE = 20Nm...
- Page 20 Page 20 of 25 LP0335 ZUSAMMENBAU ZEICHNUNG 1 ZUSAMMENBAU ZEICHNUNG 2 Unbedingt Schraubensicherungs -Lack an die 2 x Artikel 17 anbringen R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 21 Page 21 of 25 LP0335 ZUSAMMENBAU ZEICHNUNG 3 ZUSAMMENBAU ZEICHNUNG 4 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 22 Page 22 of 25 LP0335 ZUSAMMENBAU ZEICHNUNG 5 ZUSAMMENBAU ZEICHNUNG 6 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 23 Page 23 of 25 LP0335 MONTAGE ABBILDUNGEN Abbildung 1 Abbildung 2 Abbildung 3 Abbildung 4 Abbildung 5 Abbildung 6 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 24 Page 24 of 25 LP0335 MONTAGEANLEITUNG Entfernung des Originalkennzeichenhalters Entfernen Sie zuerst den Sitz wie in Abbildung 1 abgebildet. • Entfernen Sie die 2 x Schrauben unter dem Sitz, die in Abbildung 2 abgebildet sind. • Entfernen Schraube, Abbildung abgebildet...
- Page 25 Page 25 of 25 LP0335 GERINGES RISIKO, DASS DAS KENNZEICHEN AN DAS HINTERRAD STOSSEN KANN. ES LIEGT IN IHRER VERANTWORTUNG DIES ZU ÜBERPRÜFEN UND, WENN NOTWENDIG, VORBEUGENDE MASSNAHMEN ERGREIFEN. NICHTBEACHTUNG DIESES SICHERHEITSHINWEISES KANN ZU SCHWEREN VERLETZUNGEN FÜHREN. AUSGABE 1 - 04/08/2021 - (AO) CONSUMER NOTICE The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design...
