COOK QMX Series Installation, Operation And Maintenance Manual page 11

QMXU/QMXHPU
6
3
Part No.
1
2
3
4 QMXU Damper Stop
5
6 QMXU Discharge Guard (optional)
See common parts (not shown) listed on page 9.
QMX IO&M
5
4
2
Description
QMX Curb Cap
QMXU Lifting Lug
QMXU Damper
QMXU Windband
QMXLE/QMXHPLE
1
Part No.
1
2
3
4
5
6
7
See common parts (not shown) listed on page 9.
11
7
Description
QMXLE Mixing Box
QMXLE Curb Cap
QMXLE Middle Section
QMXLE Adapter Plate
QMXLE Stack Damper
QMXLE Windband
QMXLE Lifting Lug
6
5
4
3
2
1
B51092-005
