COOK QMX Series Installation, Operation And Maintenance Manual page 10

QMXE/QMXHPE
Part No.
1
2
3 QMXE Top Cap Post
4
5 QMXE Top Cap Extension (for size 90 only)
6
See common parts (not shown) listed on page 9.
QMX IO&M
4
3
2
5
Description
QMX Curb Cap
QMXE Birdscreen
QMXE Baffle Brace
QMXE Top Cap
QMXS/QMXHPS
6
1
Part No.
1
2
3
4
5
6
7
8
9
See common parts (not shown) listed on page 9.
10
7
8
4
5
9
1
Description
QMX Curb Cap
QMXS Top Cap - Open
QMXS Upper Baffle Brace
QMXS Top Cap Post
QMXS Birdscreen
QMXS Top Cap
QMXS Lower Top Cap Post
QMXS Lower Baffle Brace
QMXS Adapter Plate
6
3
2
B51092-005
