DEMO MANUAL DC2195B

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 1 C4
3 1 C5
4 1 C6
5 1 C7
6 1 C8
7 1 L1
8 1 R2
9 1 R3
10 2 R1, R4
11 1 R5
DC2195B-A Version Specific Components
1 1 U1
DC2195B-B Version Specific Components
1 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 2 C3, C10
3 1 C9
4 1 C11
5 2 C12, C13
6 1 FB1
7 1 L2
8 0 R6 (OPT.)
Hardware: For Demo Board Only
1 9 E1-E9
2 1 E10 (OPT.)
3 1 JP1
4 1 XJP1
5 4 MH1-MH4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP., X7R, 4.7µF, 50V, 10%, 1206
CAP., X7R, 0.22µF, 16V, 10%, 0603
CAP., C0G, 10pF, 25V, 5%, 0603
CAP., X7R, 47µF, 10V, 10%, 1210
CAP., X7R, 1.0µF, 25V, 10%, 0603
CAP., X7R, 0.01µF, 16V, 10%, 0603
IND., 2.2µH
RES., CHIP, 18.2k, 1/10W, 1%, 0603
RES., CHIP, 49.9k, 1/10W, 1%, 0603
RES., CHIP, 1M, 1/10W, 1%, 0603
RES., CHIP, 187k, 1/10W, 1%, 0603
IC, REGULATOR, MSE10
IC, REGULATOR, MSE10
CAP., ALUM 22µF, 63V
CAP., X7R, 4.7µF, 50V, 10%, 1206
CAP., X7R, 4.7µF, 16V, 10%, 0805
CAP., X7R, 1µF, 50V, 10%, 0805
CAP., X7R, 0.1µF, 50V, 10%, 0603
FERRITE BEAD 0805
RES., CHIP, 0Ω, 3/4W, 2010
RES., 0603
TESTPOINT, TURRET, 0.094"
TESTPOINT, TURRET, 0.094"
DOUBLE ROW HEADER 2 × 4 0.079"
SHUNT, 0.079" CENTER
STAND-OFF, NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM31CR71H475K
AVX, 0603YC224KAT2A
AVX, 06033A100JAT2A
MURATA, GRM32ER71A476KE20L
MURATA, GRM188R71E105KA12D
AVX, 0603YC103KAT2A
COILCRAFT, XFL4020-222MEC
VISHAY, CRCW060318K2FKEA
VISHAY, CRCW060349K9FKEA
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW0603187KFKEA
LINEAR TECH., LT8609AEMSE#PBF
LINEAR TECH., LT8609EMSE#PBF
SUN ELECT, 63CE22BS
MURATA, GRM31CR71H475K
MURATA, GRM21BR71C475K73L
TDK, C2012X7R1H105K
MURATA, GRM188R71H104KA93D
TDK, MPZ2012S221A
VISHAY, CRCW20100000Z0EF
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS NRPN042PAEN-RC
SAMTEC 2SN-BK-G
KEYSTONE, 8833 (SNAP ON)
