ICP DAS USA DL-10 User Manual

Rs-485 remote temperature and humidity
Hide thumbs Also See for DL-10:
Table of Contents

Advertisement

Quick Links

Download this manual
DL-10
User Manual
RS-485 Remote Temperature and Humidity
WARRANTY
All products manufactured by ICP DAS are warranted against
defective materials for a period of one year from the date of
delivery to the original purchaser.
WARNING
ICP DAS assumes no liability for damages consequent to the use of
this product. ICP DAS reserves the right to change this manual at
any time without notice. The information furnished by ICP DAS is
believed to be accurate and reliable. However, no responsibility is
assumed by ICP DAS for its use, nor for any infringements of
patents or other rights of third parties resulting from its use.
COPYRIGHT
Copyright © 2019 by ICP DAS. All rights are reserved.
TRADEMARK
Names are used for identification only and may be registered
trademarks of their respective companies.
CONTACT US
If you have any questions, please feel free to contact us via email
at: service@icpdas.com, service.icpdas@gmail.com
English Ver. 1.3, Aug. 2019

Advertisement

Table of Contents
loading

Related Manuals for ICP DAS USA DL-10

Summary of Contents for ICP DAS USA DL-10

  • Page 1 DL-10 User Manual RS-485 Remote Temperature and Humidity English Ver. 1.3, Aug. 2019 WARRANTY All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser.

  • Page 2: Table Of Contents

    PC .......................... 8 NSTALLING OFTWARE ON ..............................8 EARCH ODULE How to solve when the DCON Utility cannot find the DL-10 module? ............... 12 ............................13 ONFIGURING ODULE Configuration ................................14 AI (Humidity & Temperature) ............................ 15 MODBUS REGISTER TABLE (BASED0) ......................16 ) ..............................

  • Page 3: Introduction

    Modbus RTU communication protocol for getting measured temperature and humidity values. DCON Utility Pro provides easy and convenient interfaces for users to configure the module. Based on an amazing tiny form-factor, the DL-10 achieves the maximum space savings that allows it to be easily installed anywhere.

  • Page 4: Hardware Information

    DL-10 – RS-485 Remote Temperature and Humidity 2. Hardware Information 2.1 Appearance & Pin Assignments The front panel and Rear panel of the DL-10 module contain the Temperature and Humidity sensor, init switch, power and RS-485 connector and pin assignments. Front Panel...

  • Page 5: Specification

    DL-10 – RS-485 Remote Temperature and Humidity 2.2 Specification Temperature Sensor Measuring Range -20 ~ +60°C (-4 ~ +140 °F) Resolution 0.1°C Accuracy Typical: ± 0.4°C; refer to Figure 2 Precision ± 0.1% RH Humidity Sensor Measuring Range 10 ~ 95 % RH Resolution 0.1 % RH...

  • Page 6: Dimensions

    DL-10 – RS-485 Remote Temperature and Humidity 2.3 Dimensions The following diagrams provide the dimensions of the DL-10 module and can be used as a reference when defining the specifications for any custom enclosures. All dimensions are in millimeters. Top View...

  • Page 7: Getting Started

    DL-10 – RS-485 Remote Temperature and Humidity 3. Getting Started This chapter provides a basic overview of how to configure and operate your DL-10 module. 3.1 Connecting the Power and the Host PC Prepare for device RS-232 to RS-485 Converter: tM-7520U (optional) ...

  • Page 8: Installing Software On Your Pc

    DL-10 – RS-485 Remote Temperature and Humidity 3.2 Installing Software on Your PC Decompress DCON Utility Pro.zip, which can be obtained from the ICP DAS web site at http://ftp.icpdas.com/pub/cd/8000cd/napdos/driver/dcon_utility/ 3.3 Search Module Step 1 Run the DCON Utility Pro software Pro.exe.
  • Page 9 Select COM Port (e.g., COM9) depends on Host PC COM port that connects to DL-10. Step 4 Select the Baud Rate (e.g., 9600 and 115200) depends on DL-10 in the Baud Rate option. Copyright © 2019 ICP DAS CO., Ltd. All Rights Reserved.
  • Page 10 Select the protocol (e.g., Modbus RTU) depends on DL-10 in the Protocol option. Step 6 Select the Data Format (e.g., N, 8, 1) depends on DL-10 in the Format option and click “OK” button. Copyright © 2019 ICP DAS CO., Ltd. All Rights Reserved.
  • Page 11 DL-10 – RS-485 Remote Temperature and Humidity Step 7 Click the button to search DL-10 module. Step 8 The DL-10 module will be displayed in list and click the button. Copyright © 2019 ICP DAS CO., Ltd. All Rights Reserved. - 11 -...

  • Page 12: How To Solve When The Dcon Utility Cannot Find The Dl-10 Module

    DL-10 when normal wiring and power up, please follow the procedure described below: 1. Use the blade of a flat-head screwdriver to set the “Init Switch 1” on the DL-10 to the “ON” (Init Mode) position, and reboot the DL-10 module.

  • Page 13: Configuring Module

    In the DCON Utility Pro software, click the module name to open the “DL10 Firmware[0100]” dialog box, allowing you to configure the settings for DL-10 and verify the humidity and temperature, each of which will be described in more detail below.

  • Page 14: Configuration

    DL-10 – RS-485 Remote Temperature and Humidity Configuration After click the “Configuration” tab will display the configuration page allowing you to configure the settings for DL-10, including the Address, Baud Rate and Data Format. The following is an overview of the parameters: Item...

  • Page 15: Ai (Humidity & Temperature)

    DL-10 – RS-485 Remote Temperature and Humidity AI (Humidity & Temperature) Click the “AI” tab to see the measured humidity and temperature values. The following is an overview of the parameters: Item Description Humidity(%) Display humidity value Set the temperature to Degrees Celsius(℃) or Fahrenheit(℉)

  • Page 16: Modbus Register Table (Based0)

    DL-10 – RS-485 Remote Temperature and Humidity 4. Modbus Register Table (Based0) Discrete Inputs (1xxxx) Register Points Description Data Format Attribute 10272 0110 Read the reset status of a module. 0: The module has not been reset since the 0: Not Reset last read.

  • Page 17: Holding Register (4Xxxx)

    DL-10 – RS-485 Remote Temperature and Humidity Holding Register (4xxxx) Register Factory Points Description Data Format Attribute Value Read/Write the temperature offset -32767 ~ 40449 value (unit: 0.01℃) 32768 40485 Read/Write the Device ID 1 ~ 247 Read/Write the Baud Rate (bps)

  • Page 18: Appendix: Revision History

    DL-10 – RS-485 Remote Temperature and Humidity Appendix: Revision History This chapter provides revision history information to this document. The table below shows the revision history. Revision Date Description Aug.2019 Amended the Device ID of the factory default settings to 1 on Page 6.
