Programmable Serial-to-Ethernet Device Servers
W
ARRANTY
All products manufactured by ICP DAS are
warranted against defective materials for a period
of one year from the date of delivery to the
original purchaser.
W
ARNING
ICP DAS assumes no liability for damages
consequent to the use of this product. ICP DAS
reserves the right to change this manual at any
time without notice. The information furnished by
ICP DAS is believed to be accurate and reliable.
However, no responsibility is assumed by ICP DAS
for its use, nor for any infringements of patents or
other rights of third parties resulting from its use.
C
OPYRIGHT
Copyright © 2018 by ICP DAS. All rights are
reserved.
T
RADEMARKS
Names are used for identification purposes only
and may be registered trademarks of their
respective companies.
C
U
ONTACT
S
If you have any questions, please feel free to
contact us via email at:
service@icpdas.com, service.icpdas@gmail.com
Ver. 2.5
S
UPPORT
This manual relates to the following
modules:
PDS-5000 Series Module:
PDS-5105D-MTCP
DS-700/PDS-700 Series Modules:
DS-712, DS-715, PDS-720(D), PDS-721(D),
PDS-732(D), PDS-734(D), PDS-742(D), PDS-
743(D),
762(D), PDS-782(D), PDS-782(D)-25.
PDSM-700 Series Modules:
PDSM-721(D), PDSM-732(D), PDSM-734(D),
PDSM-742(D), PDSM-743(D), PDSM-752(D),
PDSM-755(D), PDSM-762(D), PDSM-782(D).
PPDS-700-MTCP Series Modules:
PPDS-720(D)-MTCP, PPDS-721(D)-MTCP,
PPDS-732(D)-MTCP, PPDS-734(D)-MTCP,
PPDS-742(D)-MTCP, PPDS-743(D)-MTCP,
PPDS-752(D)-MTCP, PPDS-755(D)-MTCP,
PPDS-762(D)-MTCP, PPDS-782(D)-MTCP.
PPDSM-700-MTCP Series Modules:
PPDSM-720(D)-MTCP, PPDSM-721(D)-MTCP,
PPDSM-732(D)-MTCP, PPDSM-734(D)-MTCP,
PPDSM-742(D)-MTCP, PPDSM-743(D)-MTCP,
PPDSM-752(D)-MTCP, PPDSM-755(D)-MTCP,
PPDSM-762(D)-MTCP, PPDSM-782(D)-MTCP.
PPDS-700-IP67 Series Modules:
PPDS-741-IP67, PPDS-742-IP67,
PPDS-743-IP67
PDS-752(D),
PDS-755(D),
PDS-
