Switch 4210G PWR 24-Port

Front Panel
Figure 1-5 Front panel of the Switch 4210G PWR 24-Port Ethernet switch
(1) 10/100/1000 Base-T auto-sensing Ethernet port
(2) 10/100/1000 Base-T auto-sensing Ethernet port status LED
(3) 1000 Base-X SFP port
(5) Console port
(7) Port mode LED (Mode)
(9) RPS status LED (RPS)
(11) Interface module 2 status LED (MOD2)
Rear Panel
Figure 1-6 Rear panel of the Switch 4210G PWR 24-Port Ethernet switch
(1) RPS power input
(3) Grounding screw
(5) Interface module slot 2 (MOD2)
The Switch 4210G PWR 24-Port provides two interface module slots on its rear panel. Each slot is
installed with a filler panel when the switch is shipped. You can select one or two interface modules for
your switch as needed. See
supported by the Switch 4210G, and see
installation of interface modules.
Optional Interface Modules
Connecting the RPS Power Cord
1-5
(4) 1000Base-X SFP port status LED
(6) Seven-segment LED
(8) System status LED (PWR)
(10) Interface module 1 status LED (MOD1)
(12) Port status LED mode switching button
(2) AC power input
(4) Interface module slot 1 (MOD1)
on page 1-15 for the interface module models
on page 3-14 for the
