Pepperl+Fuchs KLD2-PR-Ex1.IEC. Manual page 30

Power repeater / power supply according to IEC 61158-2
FOUNDATION FieldbusPower supply, connections and operating
Host side
DC 24 V +
DC 24 V -
Potential equalization on host side
Figure 7.7: Example: hard grounding on all field bus instruments
Host side
DC 24 V +
DC 24 V -
Potential
equalization
Figure 7.8:
Example: capacitive grounding on the power repeater/on the power sup
Subject to reasonable modifications due to technical advances.
28
Pepperl+Fuchs Group • Tel.: Germany (06 21) 7 76-0 • USA (330) 4 25 35 55 • Singapore 7 79 90 91 • Internet http://www.pepperl-fuchs.com
Field bus +
Field bus -
FE
Field bus +
Field bus -
FE
Field side
(Ex are)
Shield
Distributor box
-
+
Potential
equalization
Ex area
Field side
(Ex area)
Shield
Distributor box
-
+
Potential
equalization
Ex area
Copyright Pepperl+Fuchs, Printed in Germany
T connector/
-
+
Field device
T connector/
-
+
Field device
ply
