- Page 1 Technical Manual Ex i Power supply ENT-DC-30 ENT-DC-30, TDOCT-4038_ENG, 2015-01 Pepperl+Fuchs GmbH Mannheim...
-
Page 2: Table Of Contents
3.4.7 S-ENT/PC-9 Connecting Cable ENT-DC-30 to PC (9 pin D-Sub) ........... 17 3.4.8 S-ENT/MOUSE-9 Connecting Cable for Mouse ENT-DC-30 to PC (9 pin D-Sub) ......17 3.4.9 DATL-A 4-10 Terminal Connection (1 feed circuit) ................18 ... -
Page 3: Important Information
1 Important Information 1.1 General instructions Copyright 2014 by Pepperl+Fuchs GmbH All rights reserved The publisher reserves the right to alter the information and data contained in this manual without prior notice. Unless otherwise indicated, the company names as well as other names and data used in the examples are purely fictitious. -
Page 4: Safety Instructions
⇒ The operating voltage of the devices must not exceed the limits indicated in the "Technical Manual" under Technical data. In the event of failure to comply, Pepperl+Fuchs GmbH is not liable for any resulting damages. ⇒ The relevant specifications for hazardous areas (e.g. EN 50178, EN 60079, EN 50014 - 50039) and accident prevention regulations (e.g. -
Page 5: Symbols Used In This Manual
1.3 Symbols used in this manual The indicated specifications may not be modified. Warning: Non-compliance may result in dangerous situations and damages. Careful installation: do not replace electrical fuses Caution: with fuses from different manufacturers. Non- compliance may result in dangerous situations and damages. -
Page 6: Initial Operation
2 Initial Operation This description for initial operation refers to those issues that must be considered with respect to the power supply ENT-DC. Information with respect to operation of the peripherals connected to the ENT-DC power supply can be found in the appropriate manual. For operation proceed as follows: ... -
Page 7: Ent-Dc Power Supply
3 ENT-DC Power Supply The Exi power supply ENT-DC can be used in safe areas as a power supply for components in zone 1 and zone 2. The ENT-DC provides up to 3 feed circuits and one 20 mA CL-interface. The ENT-DC can used to feed all hazardous components which meet the interface specifications of the ENT-DC. -
Page 8: Specifications
3.2 Specifications Approval: Protection type [EEx ib] IIC Approval DMT 03 ATEX E 011 X Protection category: IP 20 Housing: Material Aluminum Dimensions refer to chapter “Housing” Weight app. 1.0 kg Environmental conditions during operation: Temperature range 0 °C - + 50 °C Humidity max. - Page 9 X3 Exi interface: Data 20 mA CL active/active switched to plus Voltage supply Version Ua [V] Ia [mA] Pa [W] ...-1..-..-2..-..-3..-..-4..-..-5..-..-6..-... Connector 2 x 4-pin integrated jack / pin contacts, for CONNECTOR-K04-508-S Note Additional output according to the approval described in the appendix can be provided upon request.
-
Page 10: Pin Assignment
3.3 Pin Assignment For the top hat rail and full housing version of the ENT-DC-2 all connections are made in the front. For the 19"- version connections can be made in the front and in the rear. All connections can be reached from the front and the back. - Page 11 Interface X3 Data- / supply interface hazardous area X3.1 2 x 4-pin terminal screw-/plug-in terminal X3.2 X3.3 X3.4 X3.5 (only assigned if 2 feed circuits) X3.6 (only assigned if 2 feed circuits) X3.7 (only assigned if 2 feed circuits) X3.8 (only assigned if 2 feed circuits) Interface X4 on front Optional data interface RS 485 to safe area...
- Page 12 Rear elevation: 19E with 1 feed circuit: 19K with 1 or 2 feed circuits: 19K with 3 feed circuits: .d .b .z .d .b .z .d .b .z .z .b .d Interface X4 DIN jack Combi-interface 1. and 2. feed circuit X4.d.2 Us2 (Exi) X4.z.2 GND (Exi) F-strip (96 pin, not all contacts equipped)
-
Page 13: Wiring
3.4 Wiring All connections for the ENT-DC are made in the front. All clamps are also directed to the 19” header for the 19" flush type version. Hence connections can be made in the rear or combined in front and rear. Note If connections are made in the front and rear the same signals should not be assigned in the front and rear at... -
Page 14: Jumpers Main Circuit Board
3.4.2 Jumpers main circuit board J1 J2 Note The jumpers J5 and J6 are designed as wiper switches on the front panel for the ENT-DC-30 versions -19K, - HS, and -AB. On the -19E version the jumpers must be placed on the circuit board. - Page 15 receiving receiving branch branch 20 mA CL interface to PC / PLC passive active sending branch sending branch passive active 20 mA CL interface to PC / PLC For ENTDC-30-100-xx2** 1 feed circuit without RS 485 normal negated logic level (X1) RS232 normal negated logic level (X1) RS232 and 20 mA CL...
-
Page 16: Jumpers Additional Circuit Board
3.4.3 Jumpers additional circuit board J3’ J4’ 1 2 3 4 SW 1 SW1 prolongation of sender activation DIP 1 DIP 2 DIP 3 Prolognation time 0,06 ms (153600 Baud) 0,12 ms (76800 Baud) 0,25 ms (38400 Baud) 0,49 ms (19200 Baud) 0,97 ms (9600 Baud) 1,95 ms (4800 Baud) 3,90 ms (2400 Baud) -
Page 17: Rs 485 Bus Termination
For this the jumper J8 has to be put on position 2-3 and J9 put on position 1-2. The ENT-DC-30 which are in the midth of the bus the termination has not to be done ( J8 in position 1-2 and J9 in... -
Page 18: Fuses
3.4.5 Fuses SI 1 2 A slow blowing (type H 1500 A ) Warning The fuse SI 1 is safety relevant. Always use the correct type fuse. The fuse SI 1 is melted by an internal protection circuit of the ENT-DC if the supply voltage (24 VDC) increases to values above 32 V. -
Page 19: S-Ent/Pc-9 Connecting Cable Ent-Dc-30 To Pc (9 Pin D-Sub)
GND 5 7 RxD DSR 6 9 GND housing CTS 8 3.4.8 S-ENT/MOUSE-9 Connecting Cable for Mouse ENT-DC-30 to PC (9 pin D-Sub) Cable required for mouse connection (EXTA-M.) to COM-port. ENT-DC 9pin D-Sub female 9pin D-Sub female 1 Tx-... -
Page 20: Datl-A 4-10 Terminal Connection (1 Feed Circuit)
3.4.9 DATL-A 4-10 Terminal Connection (1 feed circuit) ENT-DC-3.0 DATL-A 4-10 connector: 1x STECKER-K04-508-S .1 Rx .2 Tx .3 Us1 .1 Tx 1 2 3 4 .4 GND .2 Rx .3 Us1 .4 GND X1 .1 .2 .3 .4 .5 .6 .7 .8 .5 nu .6 nu Terminal... -
Page 21: Datl-A 8-10 Terminal Connection (3 Feed Circuits)
3.4.11 DATL-A 8-10 Terminal Connection (3 feed circuits) ENT-DC-3.0 DATL-A 8-10 .1 Rx .5 Us2 connector: .2 Tx .6 GND 2x STECKER-K04-508-S .3 Us1 .7 GND .1 Tx 1 2 3 4 5 6 7 8 .4 GND .8 Us3 .2 Rx .3 Us1 .4 GND... -
Page 22: Potential Equalization / Grounding
3.4.13 Potential Equalization / Grounding The ENT-DC must be connected to a potential equalization at a PA-clamp (X2.1 X2.3). If 19" flush-type versions are used potential equalization is accomplished through a screw connection with the 19" rack. The 19" rack must be connected with PA. -
Page 23: Housing
3.5 Housing Top hat rail housing (1, 2, or 3 feed circuits) 68,2 ENT-DC LED Us2 LED Us1 LED Us3 LED Tx LED Rx RS485 TTY RS232 Mounting rail TS35 (hat profile) all measurements in mm Full housing (1, 2, or 3 feed circuits) 68,2 ENT-DC ENT-DC... - Page 24 19E Slide-in card (1 feed circuit) 7 TE ENT-DC LED Us1 3 HE LED Tx LED Rx 19" row connector 19K Slide-in cassette (1, 2, or 3 feed circuits) 14 TE ENT-DC LED Us2 LED Us1 LED Us3 3 HE LED Tx LED Rx RS485 RS232 TTY...
-
Page 25: Instructions For Installation
The ENT-DC-30 must be installed so that the cooling fins either point up or down. Other components can be placed closely to the sides of the ENT-DC-30. A minimum distance of 30 mm to other components must be maintained above and below the ENT-DC. -
Page 26: Rating Plates
4 Applied harmonized standards of the applicable directives This is an addition to Pepperl+Fuchs Declaration of Conformity in accordance with EN 45014:1998 in the appendix. Directives Applied harmonized standards EC-directives... -
Page 27: Order Designations
5 Order designations 5.1 Exi Power supply ENT-DC Type ENT-DC-30 IS Power Supply & Data Interface 1. Supply circuit 1 Ua = 8 la = 280 Pa = 1,2 2 Ua = 8,5 la = 280 Pa = 1,2 3 Ua = 9... -
Page 28: Connectors
Table Ex-values of feed circuits (X = 0 : not used) Ua [V] Ia [mA] Pa [W] Distance of the devices to ... 230 m 230 m 230 m 230 m 230 m 440 m 230 m To the type code there may be attached further not safety-relevant markings. 5.2 Connectors For interface X1: CONNECTOR-SUB-D-09W... -
Page 29: Index
6 Index Block Diagram 12 Data interface 9 Environmental conditions 7 Exi interface 8 Fuses 17 Grounding 21 Housing 6, 7, 22 Slide-in card 23 Slide-in cassette 23 Support 2 Warning 4, 5, 7, 17, 21, 25 Wiring 5, 12 TDOCT-4038_ENG / 2015-01... -
Page 30: Appendix Eex Certification
7 Appendix EEx Certification...
