Power repeater / power supply according to IEC 61158-2
Total line length = length of the trunk line + total of spurs
The total maximum line length for non-Ex applications is 1900 m.
Pepperl+Fuchs GmbH offers two different power supplies:
1. KLD2-STR-1.24.400.IEC, field bus power supply current with 400 mA current for
non-Ex applications
2. KLD2-STR-NI1.13.225.IEC, field bus power supply with 225 mA supply current in
"Non Incendive" ignition protection class.
The following table shows an overview of the most important characteristic values:
Rated operational
voltage
Field side
Rated operational-
field bus instru-
ments current
Field side
max. number of
field bus instru-
a
ments
max. line length
min. line length
a.The actual number of field devices on a bus segment depends on the actual current consumption of the slaves. The specified numbe r of field devices is only
reached if the current consumption for each field device is 10 mA.
b.The actual line length depends among other things on the cable that is used and the number and distribution of slaves.
c.For max. output current and cable type A [0.8 mm² (18 AWG)]
To determine the exact maximum line length, please refer to the section "Voltage cal-
culation and line length" on
Subject to reasonable modifications due to technical advances.
18
Pepperl+Fuchs Group • Tel.: Germany (06 21) 7 76-0 • USA (330) 4 25 35 55 • Singapore 7 79 90 91 • Internet http://www.pepperl-fuchs.com
KLD2-STR-1.24.400.IEC
24 V ... 26 V
400 mA
32
b 1900 m
c 852 m
page 15 of this manual. of this manual.
FOUNDATION FieldbusGeneral
KLD2-STR-NI1.13.225.IEC
12.2 V ... 13 V
225 mA
1900 m
323 m
