Operating Instruction

Workload adjustments

Monark Compact Rehab 871 E is an arm and leg
trainer provided with a flywheel and belt brake
system. The workload can be changed either by
increasing/decreasing the rotation speed or incre-
asing/decreasing the brake force with the adjust-
ment knob.
The Compact Rehab trainer is also equipped with
an electronic meter, showing pedal revolutions
per minute (RPM), the total pedal revolutions
(TOTAL COUNT) and time (TIME) function.
2
Fig: Workload device
1) Electronic meter
2) Control knob for adjustment of work load

Computer specifications

Display
RPM
TOTAL COUNT
TIME
6
1
0 - 250 rev./min
9999 rev. total
0:00-99:59 min:sec
Monark Compact Rehab 871 E

Computer Instruction

Keys and functions:
MODE key
Use the MODE key to cycle through the func-
tions.
SET key
Pressing this key will make it possible to set TIME
and TOTAL COUNT. If you hold down this key
for 2 seconds you can advance the function value
at a faster rate.
Programming TIME:
Press MODE key to advance to TIME function,
and use SET to enter your desired time. Each
press of SET will advance time by one minute.
When pedaling is started, measurement of re-
maining exercise time will begin and the unit will
count down to 0 at which time beeper will sound
for 5 seconds.
Programming TOTAL COUNT:
Press MODE key to advance to TOTAL COUNT
function, and use SET to enter your desired
value. Each press of SET will advance value by
10. When pedaling is started, measurement of re-
maining revolutions will begin and the unit will
count down to 0 at which time beeper will sound
for 5 seconds.
RESET key
The RESET key will clear the values for TIME
and TOTAL COUNT individually.
NOTE:
1. Display will reurn to normal when not pressed
any key for 5 seconds, or trainer is not used.
2. The computer starts automatically when one
of the keys is pressed or when the trainer is used,
that is meter gets rpm indication.
3. Auto shut off function when not pressed any
key or device not used for 4 minutes.
Do not expose the fitness computer to direct
sunlight or extremely high temperature. Do not
use any dissolvents when cleaning. Use only dry
cloth.
Batteries: 1.5 V x 2
Storing temp.: -10ºC - +60ºC
Operating temp.:
R6 (AA)
0ºC - 50ºC
