Sensor Therm METIS M3F1 User Manual page 40

if X
io XX
in XY
(inX)
la X
lg X
lm X
lt XXXXXX
lx
mb
me XXXXYYYY
me XYYYYZZZZ
(meX)
mwX
oa XYYYY
(oaX)
oc XYY
(ocX)
od XX
oh XYYYY
(ohX)
op XYY
(opX)
pia XXXX
re (re0)
rf XXXX
sl
sh XYYYY
40
Communication via Serial Interface / Interface Commands
X=1...3; Debouncing time: YYYY=0x0000...03E8 (0-1000 ms)
Serial interface (only M3)
X=0...1; 0=RS232; 1=RS485 (that followed a baud rate of 19.2 KBd!)
Configure digital inputs/outputs (devices with 12-pin connector)
Bit 0 =1 => inputs 1 active / output 1 inactive, otherwise reversed;
Bit 1 =1 => inputs 2 active / output 2 inactive, otherwise reversed;
Bit 2 =1 => inputs 3 active / output 3 inactive, otherwise reversed;
Configure input X
X=1...5; YY=00...ff
YY=00 – No function
YY=01 – External clearing max. value storage
YY=02 – Targeting light on/off
YY=03 – Activate controller (controller devices)
State of targeting light (optional)
X=0...2; 0= Targeting light off; 1= Targeting light on; 2= Targeting light off toggle
Language 0 = English; 1 = German
Storage mode (maximum value storage)
0 = No storage
1 = Time clearing maximum value storage
2 = External clearing of maximum value storage
3 = Automatic clearing of maximum value storage
Clear time maximum value storage (in 100 µs steps)
XXXXXX=0x000000...03d090 (corresponds 0...25 s)
External clearing of maximum value storage
(Read) temperature range
XXXX=Beginning of temp. range; YYYY=end of temp. range (all in 1/10 degree)
Temperature sub range of pyrometer (Superordinate to the analog outputs)
XXXX=Beginning of temp. range; YYYY=end of temp. range (all in 1/10 degree)
Temp. range analog output X (X=1..2) (0...6553.5 °C/°F)
YYYY= Beginning of temp. range; ZZZZ=end of temp. range (all in 1/10 degree)
Read display temperature (current value) (4-digit hex.)
mw0 = current 2-color reading
mw1 = current reading channel 1
mw2 = current reading channel 2
mw3 = current reading channel 1+2 (4 digit hex.)
mw4 = current reading flame temperature (4 digit hex.)
Special answer format: 0xF001 = Overflow!
activation time of the digital outputs X
X=1...3; YYYY=0x0000...ffff (corresponds 0-65535 ms)
Choice of the temperature channel for digital output X
X=1...3; YY=0x00...ff
00 = 2-color, 01 = channel 1, 02 = channel 2, 03 = sum channel,
04 = display temperature, 05 = flame temperature
Output inversion (logic NO to NC)
Bit0 = 0 (digital output 1 = NO), Bit0 = 1 (digital output 1 = NC),
Bit1 = 0 (digital output 2 = NO), Bit1 = 1 (digital output 2 = NC),
Bit2 = 0 (digital output 3 = NO), Bit2 = 1 (digital output 3 = NC)
Hold time digital output X
X=1...3; hold time: YYYY=0x0000...fffe (corresponds 0-65534 ms)
(ffff => holt time infinite, until controller restart or program restart!)
Outputs (digital output X, X=1...3) YY=0x00...ff (digital function)
YY=00 – no output
YY=01 – device ready contact YY=05 – Over temperature
YY=02 – Material contact
YY=03 – limit switch contact
Automatic targeting light switch-off (optional)
XXXX=0x0000...ffff (0...65535 s)
X=0 => targeting light never turns of; X=1...65535 => switches off after X seconds
Device reset
Soot factor (only flame temperature) 4 digit hex.
XXXX=0x0032...00fah (corresponds 0.50-2.50)
Read signal strength (answer: 4-digit hex in 1/10%)
Hysteresis for signal strength contact (dirty window monitoring)
YY=04 – Controller start/stop (controller devices)
YY=05 – Setup 0
YY=04 – Signal(strength)contact
YY=06 – Setpoint limit 1
YY=07 – Setpoint limit 2
METIS M3F1
YY=08 – Setpoint band
YY=09 – Controller active
YY=0A – Control successful
