Sensor Therm METIS M3F1 User Manual page 26

 Analog Input mode: an external current enables
- To set external the soot factor or the emissivity slope ε2/ε1 or the
emissivity ε of each channel.
- Reference: Here you select whether the soot factor, the emissivity
slope or the emissivity has to be set externally.
- Time settings (response time): The sensitivity is adjustable to
compensate an analog noise at the input.
 Temperature unit:
unit will not change the entered values, no conversion will be done.
 Service functions
parameters or create service files for remote diagnosis of prob-
lems.
- Create configuration file: A configuration file includes all de-
vice settings made by user. This can be used e.g. to setup a
new pyrometer with the same values and settings or to save
the current status in case of a device replacement.
- Load Configuration file: load a previously saved configura-
tion data in the pyrometer.
- Print parameters: Prints the parameters of the currently con-
nected device.
- Print configuration file: Prints a saved file.
- Factory Settings: Resets the device to its factory defaults.
- Create service file: A service file includes all device data and
all software settings made by user. Creating such a file can
be useful if a problem can't be solved and help from our service could be useful.
- Upload service file: Transmitting a (possibly modified) file to the device it was created from.
 Interface
address (see 6.17), interface delay (see 6.17.1).
26
The temperature can be displayed and entered in °C or °F. Changing the temperature
To back up, for printing or restore device
For setting the baud rate (see 6.16), device
METIS M3F1
SensorTools Software
Function
No function v
ε2/ε1 or Emissivity ε
Reference
Soot factor
ε2/ε1 (emissivity slope)
ε of channel 1
ε of channel 2
ε of display temperature
