Data Playback - Sensor Therm METIS M3F1 User Manual

METIS M3F1
SensorTools Software
7.3

Data Playback

Press the playback button in the main windows to open a playback window and show the last
measuring values. If no device is connected, press
saved file in the playback window. Double-click on a data file, a separate viewer window opens with the
same functions.
Hold down the mouse button and drag a selection to view a detail. To select details, a selection can be
dragged with the mouse. To move the view, on the temperature or time scale the view can be moved
with the mouse (middle of the scale) or the upper and lower limits are changed (upper or lower end of
the scale).
Current mouse position
File information of the vertical mouse
position
Color settings of graphs
(same as in main windows)
Recorded data
Select and load file for viewing
Print current selection
Export the current selectionto a csv file
(e.g. to open in Excel)
Save current selection
View the complete file
If zoomed in: jump to beginning or end or
to next image section
(load data) to open and display a
31
