Terminal Block - Cosel PAA50F Instruction Manual

PAA

1 Terminal Block

l PAA50F
+Output
-Output
Frame ground
AC(L)
AC(N)
LED
l PAA75F
+Output
-Output
Frame ground
AC(L)
AC(N)
LED
l PAA100F
+Remote sensing(+S)
+Output
-Output
-Remote sensing(-S)
Frame ground
AC(L)
AC(N)
PAA-16
AC-DC Power Supplies Enclosed type
Output voltage adjustable potentiometer
Connector for Remote ON/OFF(Optional)
1: RC(+)
2: RC(-)
Output voltage adjustable potentiometer
Connector for Remote ON/OFF(Optional)
1: RC(+)
2: RC(-)
LED
Output voltage adjustable potentiometer
Connector for Remote ON/OFF(Optional)
1: RC(+)
2: RC(-)
Instruction Manual
l PAA150F
+Output
-Output
Frame ground
AC(L)
AC(N)
LED
l PAA300F
AC(L)
AC(N)
Frame ground
-Remote sensing(-S)
+Remote sensing(+S)
Current balance(CB)
Voltage balance(VB)
l PAA600F
AC(L)
AC(N)
Frame ground
Remote ON/OFF(RG)
Remote ON/OFF(RC)
Current balance(CB)
Voltage balance(VB)
-Remote sensing(-S)
June 29, 2011
Output voltage adjustable potentiometer
+Remote sensing(+S)
-Remote sensing(-S)
Connector for Remote ON/OFF(Optional)
1: RC(+)
2: RC(-)
Remote ON/OFF(RG)
Remote ON/OFF(RC)
Output voltage adjustable potentiometer
LED
+Output
-Output
Frame ground
-Output voltage monitoring(-M)
+Output voltage monitoring(+M)
+Remote sensing(+S)
Output voltage adjustable potentiometer
LED
+Output
-Output
Frame ground
