INSTALLATION and OPERATION MANUAL
Submersible Sewage Ejector
IMPORTANT:
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems constant product improvement program, product changes
may occur. As such Crane Pumps & Systems reserves the right to change product without prior
written notification.
PUMPS & SYSTEMS
420 Third Street/P.O. Box 603
A Crane Co. Company
Piqua, Ohio 45356-0603
Phone: (937) 778-8947
Fax: (937) 773-7157
www.weinmanpumps.com
Manual Index
SERIES: WE, .4 HP
1750 RPM
DISCONTINUED
Parts may
NOT be available
®
Form No. 093627-Rev. B
Advertisement
Table of Contents
Related Manuals for Crane WEINMAN WE Series
Summary of Contents for Crane WEINMAN WE Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notification.
-
Page 2: Table Of Contents
PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Weinman is a registered trademark of Crane Pumps & Systems, Inc. © Crane Pumps & Systems, Inc., 1994, 1997, 1998, 2003 Alterations Rights Reserved. - Page 3 CAUTION ! Pumps build up heat and pressure during operation-allow time for pumps to cool Crane Pumps & Systems Inc. is not responsible for losses, before handling or servicing. injury, or death resulting from a failure to observe these...
-
Page 4: Pump Specifications
SECTION: A- PUMP SPECIFICATIONS DISCHARGE: 2" (51mm) NPT, Vertical UPPER BEARING: TEMPERATURE: 104°F (40°C) Continuous. Design: Sleeve VOLUTE: Cast Iron, ASTM A-48 Class 30. Lubrication: MOTOR HOUSING: Cast Iron ASTM A-48, Class 30. Load: Radial SEAL PLATE: Cast Iron ASTM A-48 Class 30. LOWER BEARING: IMPELLER: Design:... -
Page 5: General Information
SECTION: B GENERAL INFORMATION SECTION C: INSTALLATION B-1) To the Purchaser: C-1) Location: Congratulations! You are the owner of one of the finest pumps These pumping units are self-contained and are recommended on the market today. Weinman® Pumps are products for use in a sump or basin. - Page 6 Stainless Rail Package (Not Shown)- The package system 3) If a higher pump differential is needed, grip the cord near the comes complete and ready to place into the ground as outlined neck of the float, then using the other hand, exert a steady force in the project specifications.
- Page 7 MODEL VOLT NEMA FULL LOCKED CORD CORD CORD EMERSON G.E. (Nom) CODE LOAD ROTOR SIZE TYPE WINDING WINDING AMPS AMPS RESISTANCE RESISTANCE MAIN/START MAIN/START WE411 1750 10.0 19.0 14/3 SJTOW-A 0.390 2.14--30.52 WE411A 1750 10.0 19.0 14/3 SJTOW-A 0.390 2.14--30.52 WE421 1750 14/3...
-
Page 8: Preventative Maintenance
SECTION E: PREVENTATIVE MAINTENANCE TABLE 1 - COOLING OIL - Dielectric SUPPLIER GRADE As the motor is oil filled, no lubrication or other maintenance is Enerpar SE100 required, and generally Weinman pumps will give very reliable Conoco Pale Paraffin 22 service and can be expected to operate for years on normal Mobil D.T.E. - Page 9 CAUTION: - Always wear eye protection when lbs. Rotate impeller to check for binding. Position gasket (17) working on pumps. on body and install impeller and motor housing on pump body. Apply thread locking compound to each cap screw, thread into body, and torque to 8 ft.lbs.
- Page 10 bearing (4) straight off of seal plate (2). Inspect all parts for signs F-4) Shaft Seal Service of wear and replace as needed. F-4.1) Dissassembly and Inspection: Disassemble pump motor as per section F-3.1. Inspect seal for CAUTION: - Handle seal parts with extreme care. signs of wear such as uneven wear pattern on the stationary DO NOT scratch or mar lapped surfaces.
-
Page 11: Replacement Parts
SECTION: G REPLACEMENT PARTS Insert so that the finished surface is up and the grooved surface is against the seal plate. Make sure the stationary member is in straight and that the rubber ring is not out of it’s groove. G-1 ORDERING REPLACEMENT PARTS: When ordering replacement parts, ALWAYS furnish the DO NOT HAMMER ON THE SEAL PUSHER - IT WILL... - Page 12 TROUBLESHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH "CAUSE"...
- Page 13 Fig. 9...
- Page 14 Fig. 10...
-
Page 15: Parts List
PARTS KITS Seal Repair Kit ...P/N-085202 ( ) Item No’s; 3,8c,11,13,14,16,17,19. ( ) Item No’s; 3,4,5,8c,9,11,13,14,16,17,19,21. Overhaul Kit ....P/N-085201 Seal Tool Kit ....T/L-21354 Pressure Gauge Kit..P/N-085343 PARTS LIST ITEM DESCRIPTION PART No. Motor & Sleeve 070274 Seal Plate 093063 Shaft Seal, (Standard) Carbon/Ceramic/Buna-N 068988 Tungsten/Tungsten/Buna-N... - Page 16 TABLE 2 - POWER CABLE SETS MODELS/ ITEM # 8 ITEM # 8 LENGTH WE411 WE421 15 FT (Standard) 091563 093291 25 FT 091563XB 093291XB 30 FT 091563XC 093291XC 40 FT 091563XE 093291XE 50 FT 091563XF 093291XF 75 FT 091563XJ 093291XJ 100 FT 091563XL...
-
Page 17: Returned Goods Policy
Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A "RETURNED GOODS AUTHORIZATION". - Page 18 No rights extended under this warranty shall be assigned to any other person, whether by operation of law or otherwise, without our prior written approval. PUMPS & SYSTEMS 420 Third Street/P.O. Box 603 A Crane Co. Company Piqua, Ohio 45356-0603 Phone: (937) 778-8947 Fax: (937) 773-7157...
-
Page 19: Start Up Report
This report is designed to insure the customer that customer service and a quality product are the number one priority with Crane Pumps & Systems, Inc. (CP&S). Please answer the following questions completely and as accurately as possible. Mail this form to: In U.S.A. - Page 20 CP&S Control Panel Part No. and Brand Number of pumps operated by control panel NOTE: At no time should holes be made in top of control panel, unless proper sealing devices are utilized. Control Panel Manufactured by Others: Company Name: Model No.
-
Page 21: Warranty Registration
Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. FOLD HERE ** IMPORTANT ! ** WARRANTY REGISTRATION CUSTOMER’S NAME... - Page 22 FOLD HERE AND TAPE, DO NOT STAPLE PLACE STAMP HERE CRANE PUMPS & SYSTEMS, INC. WARRANTY SERVICE GROUP 420 THIRD STREET P.O. BOX 603 PIQUA, OHIO 45356-0603 - U.S.A.
