5.3.5 Install Batteries
Reference Figure 6.
Insert 2 x AA non-rechargeable batteries (not included) into the battery
compartment. The LED indicator on the back of the transmitter will turn on for four seconds, and then
flash once every 16 seconds (the sensor transmission update period).
(a)
Note: If the LED does not light up, or stays on permanently, make sure the battery polarity is
correct, or the batteries are fresh. Do not install the batteries backwards. You can permanently damage
the thermo-hygrometer.
Note: We recommend lithium batteries for cold weather climates, but alkaline batteries are
sufficient for most climates. We do not recommend rechargeable batteries. They have lower voltages,
do not operate well at wide temperature ranges, and do not last as long, resulting in poorer reception.
Version 2.12
Figure 5
Figure 6
©Copyright 2020, Ambient LLC. All Rights Reserved.
(b)
Page 8
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the WS-2000 and is the answer not in the manual?
Questions and answers
Ws 2000 display not connected to weather underground or ambient weather networks. I can’t get any assistance from weather underground. Can you help me?
If the Ambient Weather WS-2000 display is not connecting to Weather Underground or Ambient Weather networks, follow these steps:
1. Check Wi-Fi Connection: Ensure the display is connected to a 2.4 GHz Wi-Fi network. The WS-2000 does not support guest networks.
2. Look for Exclamation Mark (!): If an exclamation mark appears next to the Wi-Fi icon, the display is connected to Wi-Fi but not to the Internet.
3. Confirm Internet Access: Make sure your router’s 2.4 GHz band is connected to the Internet.
4. Reboot Router: If the issue persists, restart your router.
5. Verify Firmware: Check if the Wi-Fi firmware is updated using the awnet app. If the WS-2000 is not listed in the app, this step may not be possible.
6. Factory Reset: If other steps fail, perform a factory reset on the console and re-enter your Wi-Fi credentials after disabling the 5 GHz band.
These steps should help resolve the connection issue.
This answer is automatically generated
how do you delete a sensor
To delete a sensor on the Ambient Weather WS-2000, you need to re-register the outdoor transmitter. This process removes the previous sensor registration. Follow these steps:
1. Highlight the "Re-register Transmitter Outdoor" field.
2. Press the select key to open the message box: "Are you sure you want to register the new outdoor transmitter?"
3. Select "Yes" to confirm.
This action will remove the previous sensor and allow a new one to be registered.
This answer is automatically generated
When plugging in WS-2000 it just beeps with "Starting" flashing on screen.
The Ambient Weather WS-2000 beeps and displays "Starting" when plugged in due to a possible issue with the boot process. This can be caused by a corrupted bootloader, a failed firmware flash, or an inadequate power supply that drops voltage under load. If resetting the device and replacing the internal battery do not fix it, the display unit or internal components may be damaged.
This answer is automatically generated
