Summary of Contents for Tyco Electronics SOLARLOK 4-1394462-6
- Page 1 SOLARLOK Interconnection System Installation Manual...
-
Page 2: Safety Note
(2) Crimping Tool 4.0 mm and 6.0 mm , 10-12 AWG PN 1-1579004-2 (3) Extraction Tool all terminals PN 1102855-3 (4) Field Service Kit all in one PN 1534858-1 All specifications subject to change. Consult Tyco Electronics for latest specifications. tycoelectronics.com/solar... -
Page 3: Assembly Steps
Press the seal and cable pinch ring assembly into the connector housing until it stops. If you use the pre-assembled connector kit, please go to 3.5! Screw back shell nut onto connector housing. All specifications subject to change. Consult Tyco Electronics for latest specifications. tycoelectronics.com/solar... -
Page 4: Connector Mating
“+” or “-” keyed plug connectors. The neutral product should not be used when maintaining polarity is critical. It is only permitted for serial connections. All specifications subject to change. Consult Tyco Electronics for latest specifications. tycoelectronics.com/solar... - Page 5 2-1773458-2 SOLARLOK Interconnection System Issued 8-2010 Installation Manual 5. Wiring Radius (r) min. 5x cable Ø r = correct! 6. Connector Unmating Depress locking latches Pull apart All specifications subject to change. Consult Tyco Electronics for latest specifications. tycoelectronics.com/solar...
- Page 6 Neutral Male 4.0mm / 12AWG 4.5 to 6.0 mm / 0.177-0.236 in 7-1394461-5 Neutral Male 6.0mm / 10AWG 4.5 to 6.0 mm / 0.177-0.236 in Male housing Female housing All specifications subject to change. Consult Tyco Electronics for latest specifications. tycoelectronics.com/solar...
