Suggested Installation Equipment
(not supplied with kit)
• Cable preparation tools
• Tyco Electronics P63 cable preparation kit or cable manufacturer
approved solvent
• Clean, lint-free cloths
• Non-conducting abrasive cloth, 120 grit or finer
• Electrician's tape
• Connector(s) and installation tools
• Tyco Electronics recommended torch
Safety Instructions
DANGER: When installing electrical power system accessories,
failure to follow applicable personal safety requirements and written
installation instructions could result in fire or explosion and serious or
fatal injuries.
To avoid risk of accidental fire or explosion when using gas torches,
always check all connections for leaks before igniting the torch and
follow the torch manufacturer's safety instructions.
To minimize any effect of fumes produced during installation, always
provide good ventilation of confined work spaces.
As Tyco Electronics has no control over field conditions which
influence product installation, it is understood that the user must
take this into account and apply his own experience and expertise
when installing product.
PII 54917, Rev AJ
HVS-T-1580E-S
15kV Class Trifurcating Transition Splice for 3/C
PIL to 3 1/C Extruded Dielectric (Poly/EPR) Power
Cables
Recommended Tyco Electronics Torches
Install heat-shrinkable cable accessories with a "clean burning" torch,
i.e., a propane torch that does not deposit conductive contaminants
on the product.
Clean burning torches include the Tyco Electronics FH-2629,
FH-2649 (uses refillable propane cylinders) and FH-2618A (uses
disposable cylinder).
Adjusting the Torch
Adjust regulator and torch as required to provide an overall 12- inch
bushy flame. The FH-2629 will be all blue, the other torches will have
a 3- to 4-inch yellow tip. Use the yellow tip for shrinking.
Regulator Pressure
FH-2618A
Full pressure
FH-2649
25 psig
FH-2629
15 psig
General Shrinking Instructions
• Apply outer 3- to 4-inch tip of the flame to heat-shrinkable material
with a rapid brushing motion.
• Keep flame moving to avoid scorching.
• Unless otherwise instructed, start shrinking tube at center,
working flame around all sides of the tube to apply uniform heat.
To determine if a tube has completely recovered, look for the following,
especially on the back and underside of the tube:
1. Uniform wall thickness.
2. Conformance to substrate.
3. No flat spots or chill marks.
4. Visible sealant flow if the tube is coated.
Note: When installing multiple tubes, make sure that the surface of
the last tube is still warm before positioning and shrinking the next
tube. If installed tube has cooled, re-heat the entire surface.
1
PCN 307937-000
Effective Date: March 13, 2007
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Tyco Electronics Raychem HVS-T-1580E-S Series
Summary of Contents for Tyco Electronics Raychem HVS-T-1580E-S Series
- Page 1 Recommended Tyco Electronics Torches • Cable preparation tools Install heat-shrinkable cable accessories with a “clean burning” torch, • Tyco Electronics P63 cable preparation kit or cable manufacturer i.e., a propane torch that does not deposit conductive contaminants approved solvent on the product.
-
Page 2: Installation Instructions
Additional braid may be needed for LC shield, lead sheath cables, or if external grounding or shield interrupting is required. Tyco Electronics HVS-EG supplies ground braid, spring clamp and suggested modifications to make an external ground or shield interrupt. - Page 3 CHOICE 2 If PILC to Drain Wire Shield Cable PILC Poly Refer to Table 2 and prepare the cables as shown. Go to Step 4. CHOICE 3 If PILC to UniShield Cable PILC Poly Refer to Table 2 and prepare the cables as shown. Pull back the drain wires to Dimension A.
- Page 4 Table 4 Poly Poly PILC Wire Cutback Semi-con Cutback Lead Sheath Cutback HVS-T-1581E-S 12” (305mm) 4-1/2” (114mm) 15” (381mm) HVS-T-1582E-S 13” (330mm) 5-1/2” (140mm) 16” (406mm) HVS-T-1583E-S 14” (356mm) 6” (152mm) 17” (432mm) *If the 3/C PILC cable has an outer jacket, remove the jacket to dimension “C” plus 5.0”(127mm). 4.
- Page 5 7. Position OBT; shrink in place. Place a CLEAR Oil Barrier Tube (OBT) over each phase, butted to the lead sheath (or belt paper) cutback. Shrink the three OBTs in place starting at the lead sheath cutback. PILC Note: To achieve a smooth, wrinkle-free installation, use a Lead reduced flame to install the thin-walled OBT.
- Page 6 13. Trim excess SRM insert. Trim SRM insert to extend 1/8” (3mm) beyond each phase. PILC Trim SRM Insert 14. Clean lead sheath. Clean 6"(150mm) Lead Reclean lead sheath as shown using an approved solvent Sheath PILC 15. Mark lead sheath as shown. 1-1/2"...
-
Page 7: Install Connectors
Refer to Table 5 and cutback the insulation as shown. "Z" "X" "Y" Insulation 1/2 Length Expansion Note: If using Tyco Electronics CSBS ShearBolt connectors, Cutback of Connector refer to the installation instruction packaged wtih the connector for insulation cutback dimensions. Table 5: Connector Dimensions Expansion Max Length Max O.D. - Page 8 23. Apply SRM over connector. Stretch SRM to 1/2 Original Width Remove backing from one side of a long strip of SRM. Roll the SRM and remaining backing strip into a convenient size. Removing the remaining backing strip, tightly wrap the SRM around the connector and exposed conductor.
- Page 9 26. Position black stress control tube. Center black stress control tube over the completed connector Black Stress Control Tube area. Be sure to equally overlap the Poly cable semi-con and the PILC cable black conductive tube. Repeat Steps 22-26 for the remaining two phases. 27.
- Page 10 29. Position black/red dual layer tubes; shrink in place. Black/ Red Dual Layer Tube Note: Black/red dual layer tubes take longer to shrink than previous tubes. Center tubes over joint. (1) Begin shrinking in center of tubes, working torch around all sides of the tubes.
- Page 11 Braid CHOICE 2 Connector If Drain Wire or UniShield Cable Pigtail the shield wires and crimp on to the ground braid using the connectors provided. Go to Step 31. CHOICE 3 Ground Ground Spring Braid Braids Clamp If Metallic Tape or LC Shield Cable 1/C SIDE ONLY (1) Flare one end of the ground braid and place it onto the metallic tape, butted up to the end of the tubes.
- Page 12 CHOICE 5 Ground Braid If Jacketed Concentric Neutral Cable Connector Pigtail the neutral wires and crimp or solder to the ground braid. Go to Step 31. *Not supplied in kit. 31. Install ground on 3/C PILC side of splice. 3 layers shielding mesh Choose the application (Choice 1-2) and follow the directions given.
- Page 13 34. Position non-conductive sealing breakout; shrink in place. Sealing Breakout Make sure that the full length of the fingers of the breakout are over the extruded dielectric cable jackets with the body extending over the splices. Shrink in place starting at the fingers and working toward the splice center.
- Page 14 37. Install ground clamp, solder block braids, apply 2 more wraps spring clamp sealant. Apply 2 more wraps of the spring clamp. 1821l Fold back the braids back over the spring clamp and wrap the remaining spring clamp. Tighten and secure the spring clamp. Fold braids back over &...
-
Page 15: Install Channels
38. Apply shielding mesh. Copper Shielding Mesh Starting over the ground connections on the extruded dielectric side of the splice, wrap one half-lapped layer of 2 inch (50mm) wide shielding mesh across the splice and tie off with a slip knot to the PILC cable lead sheath. Abrade and solvent clean cable jackets (or lead sheath) as 4"... - Page 16 43. Shrink wraparound sleeve. Preheat evenly along both sides of the rail/channel area until this area begins to shrink. To achieve uniform heating, move the flame back and forth from one side of the channel to the other as shown in illustration “A” while moving flame along the entire length of the channel as shown in illustration “B”...
- Page 17 4. Apply red sealant. One wrap Red Sealant Apply one layer of red sealant onto the cable jacket as shown. 5. Apply red sealant. One wrap Red Sealant Bring the braids forward and temporarily tape them to the PILC cable to hold them in position. Press the braids onto the sealant.
- Page 18 However, Tyco Electronics has no control over the field conditions which influence product installation. It is the user’s responsibility to determine the suitability of the installation method in the user’s field conditions. Tyco Electronics’ only obligations are those in Tyco Electronics’ standard Conditions of Sale for this product and in no case will Tyco Electronics be liable for any other incidental, indirect or consequential damages arising from the use or misuse of the products.
