Control systems
7.2.5 Connectors
CR721S
Connectors
CAN0
CAN1 + RS-232
ETH0 / ETH1
Connector A
Connector B
ifm electronic gmbh ● Friedrichstraße 1 ● 45128 Essen
Connector A
M12 socket, 5 poles, A-coded
1: not used:
2: not used:
3: GND_COM
4: CAN0_H
5: CAN0_L
M12 socket, 5 poles, A-coded
1: RS-232_TxD
2: RS-232_RxD
3: GND_COM
P_MZ_e100_0093
P_MZ_e100_0093
4: CAN1_H
5: CAN1_L
M12 socket, 4 poles, D-coded
1: TxD+
2: RxD+
3 : TxD-
4: RxD-
AMP, 81-pole, A-coded
1-81: see wiring
connector A
AMP, 81-pole, B-coded
1-81: see wiring
connector B
We reserve the right to make technical alterations without prior notice!
ecomatController CR720S/CR721S
Technical data
CAN0 ETH0 Connector B
CAN1 + ETH1
RS-232
63
44
25
6
63
44
25
6
CR721S / page 11
Original Scale Drawing (MTD
Scale: 1:2
UK
Original Scale D
Original Scale D
Scale: 1:2
Scale: 1:2
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 49,5 m
81 2 1
62
3
43
24 5 4
81 2 1
62
3
43
24 5 4
EPS Source
EPS Source
Product Scale D
Product Scale D
Frame Size: 80
Frame Size: 80
22 Nov� 2017
