7.1.7 Connector B / wiring
CR720S
Wiring
GND
GND
Supply +
Inputs
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
Abbreviations
ifm electronic gmbh ● Friedrichstraße 1 ● 45128 Essen
32
Connector B
Supply
Con. B
06 IN1100 A, B
L
07 IN1101
A, B
L
08 IN1102 A, B
L
09 IN1103 A, B
L
36 IN1600 A, B
L
37 IN1601 A, B
L
38 IN1602 A, B
L
39 IN1603 A, B
L
44 IN1000 B , FRQ
L/H L/H
45 IN1001 B , FRQ
L/H L/H
46 IN1002 B , FRQ
L/H L/H
47 IN1003 B , FRQ
L/H L/H
59 IN1500 B , FRQ
L/H L/H
60 IN1501 B
, FRQ
L/H L/H
61 IN1502 B , FRQ
L/H L/H
62 IN1503 B , FRQ
L/H L/H
10 IN1200 B (10 kΩ)
L
11 IN1201 B (10 kΩ)
L
12 IN1202 B (10 kΩ)
L
13 IN1203 B (10 kΩ)
L
40 IN1700 B (10 kΩ)
L
41 IN1701 B (10 kΩ)
L
42 IN1702 B (10 kΩ)
L
43 IN1703 B (10 kΩ)
L
25 IN1300 B (3,2 kΩ)
L
26 IN1301 B (3,2 kΩ)
L
27 IN1302 B (3,2 kΩ)
L
28 IN1303 B
(3,2 kΩ)
L
A analogue
B binary high side (CSO)
H
B binary low side (CSI)
L
FRQ frequency/pulse inputs confi gurable low side (CSI) / high side (CSO)
L/H
H H-bridge function
PSU pulse width modulation for the system
pulse-width modulation high side (CSO)
PWM
H
PWM pulse-width modulation low side (CSI)
L
PWM pulse-width modulation current-controlled
I
R resistance input
VBB supply output group via semiconductor switch
0���3
VBB supply sensors/module
30
