ecomatController CR720S/CR721S

7 Technical data

7.1 CR720S
Control systems
7.1.1 Mechanical and electric data
CR720S
ecomatController/98
32-bit CPU TriCore processor
98 inputs/outputs
4 CAN interfaces
Ethernet interface
CODESYS 3�5
8���32 V
Technical data
Mechanical data
Housing
Dimensions (H x W x D)
Mounting
Connection
Weight
Housing/storage temperature
Max� perm� relative humidity
Height above sea level
Protection rating
Electrical data
Input/output channels total
Inputs
Outputs
Sensor supply
Operating voltage
Overvoltage
Reverse polarity protection
Current consumption VBB
ifm electronic gmbh ● Friedrichstraße 1 ● 45128 Essen
20
P_MZ_e100_0093
for the implementation of a central or decentralised system design
2 x connector 81-pole, locked, mechanical reverse polarity protection, type Tyco /
contacts AMP-Junior-Timer, crimp connection 0�5/0�75/2�5 mm²
IP 65 / IP 67 (for inserted connectors with individually sealed cores and inserted
30
We reserve the right to make technical alterations without prior notice!
LEDs
271
250
6,4
Controller as black box system
closed, screened metal housing with screw connection
219 x 271 x 47 mm
screw connection by means of 4 M6
AMP
LEDs
2 x M12 connector 4 poles, D-coded
2 x M12 connector 5 poles, A-coded
Shield connection Ø 4 mm for self-tapping screw
6,4
1�6 kg
– 40���85 °C (depending on the load) / – 40���85 °C
90 % (not condensing)
max� 3000 m
M12 connectors/sealing caps)
98 (60 inputs / 38 outputs)
confi gurable, with diagnostic capability
24 x A (0���10/32 V, 0���20 mA, ratiometric) / B
16 x FRQ (≤ 30 kHz) / B
L/H
4 x R (0�016���30 kOhm) / B
8 x B (impedance ≤ 10 kOhm)
L
8 x B (impedance ≤ 3.2 kOhm)
L
confi gurable, with diagnostic capability
8 x PWM / PWM / B (20���2000 Hz, 4�0 A, H-bridge)
H/L I H/L
4 x PWM / PWM / B
H I
12 x PWM / PWM / B
H I
12 x PWM
2 x A (0���10 V)
1 x 5/10 V, max. 2 W confi gurable
for the number of inputs/outputs and confi guration options also
see the wiring diagrams
8���32 V
36 V for t ≤ 10 s
yes
max� 600 mA at 12 V
max� 400 mA at 24 V
Original Scale Drawing (MTD)
Scale: 1:2
47
18
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 49,5 mm
271 47
250 18
1 M12x1 2
L
L/H
L
(20���2000 Hz, 4�0 A)
H
(20���2000 Hz, 2�5 A)
H
/ B 2�5 A
H H
CR720S / page 1 22 Nov� 2017
