Tools and screw sets
Drawing
Part no. and description
88) Spring washer (M8)
92) Washer (8x38x2.0t)
100) Screw (M5xp0.8x15mm)
101) Screw (M5xp0.8x30mm)
113) Screw (M8xp1.25x65mm)
115) Screw (M10xp1.5x70mm)
116) Screw (M10xp1.25x85mm)
126) Nylon nut (M10xp1.5)
96) Screw (M4x20mm)
100) Screw (M5xp0.8x15mm)
105) Screw (M8xp1.25x10mm)
117) Screw (M10xp1.5x50mm)
Qty.
4
4
16
2
4
2
2
4
3
18
8
2
13
