Appendix

If there is no Image

Ensure the input source is sending a signal.
Check the input source is correctly connected, an LED will flash on the input board
at the rear of the projector if you have incorrectly connected the input device. Check
that a signal is being sent (e.g. if it is a video recorder, it is set to play).
Ensure the correct input and channel numbers have been selected.
Check the type of input source and the input number you have connected the device
to, then, select the appropriate settings in the Channel Set-up Function.
Ensure Pic Mute has not been inadvertently selected.
If Pic Mute is ON, press the Pic Mute button on the remote control to toggle it OFF.

Correcting Distorted Images

The image is out of focus.
Ensure the projector is placed in the correct position, then focus the image by
using the manual controls located underneath the front hatch.
The image does not fit the screen.
Ensure the projector is placed in the correct position, then select the channel with
the required aspect ratio for the image you want to display. The aspect ratio can be
changed using the Modify option in the Channel Set-up function.
The image is stretched horizontally or vertically.
The image is being displayed with the wrong aspect ratio. Before changing the
aspect ratio, ensure you have selected the correct channel for your input device and
the horizontal and vertical sizes are correct.
