Digital Projection POWER 2v User Manual page 152

Advanced User Information
Technical Specification
Lamp Type
ANSI Output
Lamp Life
Brightness Linearity
Colour Temperature
Contrast Ratio
Display Type
DMD Specification
Fill Factor
Input Specification
RGBS
Y Pr Pb
Y/C (S video)
Composite
Computer
Source Compatibility
DÑ44
POWER 2v POWER 4dv
Proprietary Xenon Arc
2500 Lumens 3500 Lumens
1000 hours 750 hours
>90% Edge to Centre
3000K - 9300K adjustable
>150:1 ANSI Checkerboard
>200:1 Full Field
3 x DMD (one per R, G & B)
848 x 600 Pixels
16um x 16um Pixel size
17um x 17um Pixel pitch
14.4mm x 10.2mm DMD size
88% Pixel fill factor
3 independently configurable inputs - selectable via
remote control. BNC connectors 525/60, 625/50, PAL,
NTSC, SECAM, SVGA,VGA, XGA & MAC
Auto Select.
RGB = 700 mV/75R
S = 0.7 V - 5 V
Sync on G, Separate H & V,
Composite Sync Auto Select.
Y = 700 mV + 300 mV/75R
Pr, Pb = 700 mV p-p/75R
Y = 700 mV + 300 mV/75R
C = 300 mV p-p/75R
1 V p-p/75R
H = 15 kHz to 79 kHZ
V = 24 Hz to 100 Hz
up to 800 x 600 up to 1024 x 768
@ 100Hz @ 100Hz
LBV00018; Revision E - 28/01/98
POWER 5dv
5000 Lumens
500 hours
up to 1024 x 768
@ 100Hz
