INSTALLATION, OPERATION & MAINTENANCE MANUAL
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
DEMING
DEMING
Vertical Process Pumps
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Series: 5460
Form No. 120024-Rev. C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crane DEMING 5460 Series
Summary of Contents for Crane DEMING 5460 Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
-
Page 2: Table Of Contents
CROSS-SECTION & PARTS LIST ...........9 WARRANTY & RETURNED GOODS ..........11 Other brand and product names are trademarks or registered trademarks of their respective holders. Deming® is a registered trademark of Crane Pumps & Systems, Inc. 1996, 10/06 Alteration Rights Reserved... -
Page 3: Safety First
Crane Pumps & Systems, Inc. is not responsible for WARNING ! Do not pump hazardous materials losses, injury, or death resulting from a failure to observe (fl... -
Page 4: General Information
Remove motor cap screws (219) and disengage Systems Service Department in Piqua, Ohio, telephone (937) 778-8947 or Crane Pumps & Systems Canada, Inc., the shaft coupling. Jog control to test for proper pump rotation. Standard pump rotate clockwise when looking Bramton, Ontario, (905) 457-6223. -
Page 5: Pump Adjustment
F - PUMP ADJUSTMENT I - LUBRICATION If after making the installation as above and the pump The pump bearings (18) and (16) and the lip seals (47) shaft does not rotate freely or if there is vibration and (49) were properly lubricated at the factory before in the pumping unit, the following adjustments are shipment. -
Page 6: To Inspect Ball Bearings & Seal Or Shaft
If the pump is furnished with threaded discharge Inspect the throttle bushing (252) for excessive fi ttings, unscrew the pipe coupling or fl ange wear and replace by unscrewing the cap screw (295) from the top end of the discharge pipe (218) and pressing the bushing from the then remove the top pipe nut (294) and unscrew housing. -
Page 7: Assembly Of Liquid End
O - CHAIR BRACKET MOUNTING Insert shaft with bearing, impeller end fi rst, into the top of the frame (19) being careful not to damage the seal (47). (See page 8) The foot mounted horizontal type motor and fl exible shaft Place bearing housing (33) in a vice with the fl... -
Page 8: Chair Bracket Mounting
Chair Bracket Mounting Motor Support Motor Mounting Screw Lock Nut Motor Foot Motor Anchor Cap Screw P - LOCATING TROUBLE 3. Not enough pressure a. Air in water b. Mechanical defects 1. No water delivered c. Impeller diameter too small a. -
Page 9: Cross-Section & Parts List
ITEM No. DESCRIPTION Casing Impeller Shaft Suction Cover *016 Ball Bearing (Inboard) *018 Ball Bearing (Outboard) Frame Lock Nut (Bearing) Base Plate *024 Impeller Nut Impeller Key Bearing Housing (Outboard) Bearing Cover (Inboard) Bearing Cover (Outboard) Defl ector Coupling Coupling Key *047 Bearing Cover Seal *049... - Page 10 Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state.
-
Page 11: Warranty & Returned Goods
Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material. - Page 12 Notes...
