First Start; Controller’s Connections Checking - Selbit ISP - 010 Manual Handbook

Incorrect connection of the rotating or magnetic encoder may cause its serious damage!!
Next step after creating all of the connections is assembly of the controller's casing. Before
connecting from panel with the back side please check if the rubber sealing is in the special
groove. It is important in regarding sealing and protecting controller's main electronic plate
from any contamination. After put the from panel in together with the back side please screw
casing using included six screws 4,1x12. Before mounting the controller on the machine it is
recommended to checking of proper controller's operating according to "first start" chapter
(2). After checking of the controller's proper operating please use safety plugs in the places
where screws are and mount the controller on the machine. Controller's mounting in the main
machine's board is analogical, there is only one difference that front panel is screwed from
the inside with plastic frame and main panel casing. After all mounting please carefully pull
out cables which go out at the back side of the controller's casing to reduce their unnecessary
length in the inside. Please be careful to not destroy any connection. After this operation
please screw PG choke to create proper sealing. Next step, in case the controller as a separate
devise, please mount it using four 4,1x10 screws on the sawing frame machine. Screws should
go though four holes in the back casing created for this purpose.
To check correctness of the controller's connections, please follow the instruction below:
- after turning on please notice text ISP 010 on the display. If the text is doesn't show
please check connections of the transformer TSS8/001 and try again.
- next after the sign disappear, please press head saw up feeding button placed on the main
panel. During manual up or down feeding, please notice if the saw height on the display
changes accordingly. During down feeding, the value should decrease and while up
feeding should increase. If this operation brings false result, that means the value of the
saw height increase during down feeding or decrease while up feeding, please switch the
connections of the encoder. In case of the rotating encoder, please exchange black with
white cable and in case of the magnetic encoder MSK-320 red with orange cable (
ENCODER junction, In1, In2). Next check values displaying once again. This operation is
really important, if saw height counting goes wrongly, it may cause incorrect controller's
working.
- after above operation, please press 8 button on the "Board Thickness" panel and the
number 8 should be displayed. Now press "Start/Next Cut" button and the controller
should move the head saw a little bit down. If this movement is up, please check the
connections with up and down feeding and it is required exchange junctions DWN with
CAUTION!!!
CHAPTER 2

First start

Controller's connections checking
