Using this mode you can easily and automatically divide laying log on the required
cut dimension. Basic for dividing is provided dimension and its actual value is shown in the
window "Board Thickness".Using this dimension the controller counts number of the boards
available till the saw height. It gives the possibility of quick programming from any
dimension provided by user before.
While using this mode the dimension can be easily change and user can use many positions
and the controller each time counts the new number of boards available from actual head saw
position. To use this quick program follow instructions below.
Set up the head saw on the top of the log (position of the firs cut). Press shortly "Quick
Program" button, the led is on and text "Str Pro" is displayed and then the nearest available
cut positions is displayed as well.
Now the lower positions can be changed, fit them to the requirements or position
the head saw using "Start/Next Cut" button. Trial without positioning of the head saw is
automatically rejected by the controller and text "Pres Cut" is displayed.
During providing the changes on the each positions, those which can not be fit into are
rejected by the controller.
If changes on the positions (lower positions) allows to add new one to the program, the
controller adds them automatically.
After programming, please position the head saw using "Start/Next Cut" button. The
controller sets up the head saw automatically up to counted positions, if there is a possibility
of adding any positions, the controller display d character and just next to it shows the
maximal dimension available to add.
If it is required to add cut dimension, please using up arrow button go to upper position and
provide new value from the range provided by the controller. Providing bigger dimension
which exceed the saw height it is signal by displaying "Pro Full" text while position the head
saw using "Start/Next Cut" button.
If the new positions was added, next it is possible to position the head saw again and
save program using "Save Program" button or before saving set up the head saw on the
backward height and then save the program (if it is required to use the settled backward saw
height as it is in case manual program). If the tip dimension is not being used, please save the
program without providing it.
