Industrial Electronic Devices
CHARACTERISTICS:
The HD67949-B2 is a NMEA2000 / MQTT Converter.
It allows the following characteristics:
Electrical isolation between Ethernet and NMEA2000;
Mountable on 35mm Rail DIN;
Wide power supply input range: 18...35V DC and 8...24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67949 software on your PC in order to perform the following:
Define the parameter of MQTT;
Define the parameter of NMEA2000 line;
Define the MQTT topics to be published/subscribed in the MQTT Server;
Define the list of NMEA2000 messages in reception and transmission;
Update the device.
ADFweb.com S.r.l.
User Manual NMEA2000 / MQTT
Document code: MN67949_ENG
Revision 1.000
Page 6 of 32
