- Page 1 Page 1 of 34 Industrial Electronic Devices User Manual Revision 1.000 English BACnet slave / MQTT - Converter (Order Code: HD67938-IP-B2, HD67938-MSTP-B2) For Website information: For others MQTT products, see also the following links: www.adfweb.com?Product=HD67938-B2 Converter MQTT to www.adfweb.com?Product=HD67930 (Ethernet) For Price information: www.adfweb.com?Product=HD67931...
-
Page 2: Table Of Contents
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 2 of 34 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 3 of 34 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 4 of 34 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 5 of 34 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67938-IP-B2 ADFweb.com S.r.l. - Page 6 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 6 of 34 Industrial Electronic Devices Figure 1b: Connection scheme for HD67938-MSTP-B2 ADFweb.com S.r.l.
-
Page 7: Characteristics
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 7 of 34 Industrial Electronic Devices CHARACTERISTICS: The HD67938-B2 is a BACnet slave / MQTT Converter. It allows the following characteristics: Mountable on 35mm Rail DIN; Wide power supply input range: 18…35V DC and 8…24V AC; Wide temperature range: -40°C / 85°C [-40°F / +185°F]. -
Page 8: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67938-IP-B2 HD67938-MSTP-B2 Caution: Not reverse the polarity power HD67938-B2 ADFweb.com S.r.l. -
Page 9: Function Modes
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 9 of 34 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... -
Page 10: Leds
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 10 of 34 Industrial Electronic Devices LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 11: Rs485
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 11 of 34 Industrial Electronic Devices RS485 (for BACnet MS/TP): For terminating the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). -
Page 12: Ethernet
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 12 of 34 Industrial Electronic Devices ETHERNET: The Ethernet port is used for programming the device and for MQTT and BACnet/IP communication. The Ethernet connection must be made using Connector2 of HD67938-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. -
Page 13: Use Of Compositor Sw67938
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 13 of 34 Industrial Electronic Devices USE OF COMPOSITOR SW67938: To configure the Converter, use the available software that runs with Windows called SW67938. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 14: New Configuration / Open Configuration
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 14 of 34 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “BACnet Slave / MQTT - Converter”... -
Page 15: Software Options
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 15 of 34 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 16 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 16 of 34 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 17: Set Communication
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 17 of 34 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67938 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in different sections in order to define the different parameters of the converter: BACnet Slave... - Page 18 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 18 of 34 Industrial Electronic Devices /IP): LAVE This section is used to define the main parameters of BACnet/IP line. The means of the fields are: In the fields “IP ADDRESS”...
- Page 19 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 19 of 34 Industrial Electronic Devices MS/TP): LAVE This section is used to define the main parameters of BACnet MS/TP line. The means of the fields are: In the field “Baudrate” the data rate of the BACnet line is defined; In the field “Parity”...
- Page 20 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 20 of 34 Industrial Electronic Devices MQTT: This section is used to define the main parameters of MQTT line. The means of the fields are: In the field “Server URL”...
- Page 21 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 21 of 34 Industrial Electronic Devices THERNET This section is used to define the general parameters of Ethernet. The means of the fields are: In the field “Ip Address”...
- Page 22 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 22 of 34 Industrial Electronic Devices If the field “Enable DHCP” is checked, the converter acts as DHCP Server for the Clients connected. If the option is enabled, in the fields “DHCP First IP Address”...
- Page 23 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 23 of 34 Industrial Electronic Devices TLS (T RANSPORT AYER ECURITY This section is used to define the parameters of TLS protocol. The means of the fields are: If the field “Enable TLS”...
-
Page 24: Mqtt Set Topic
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 24 of 34 Industrial Electronic Devices MQTT SET TOPIC: By Pressing the “MQTT Set Topic” button from the main window for SW67938 (Fig. 2) the window “Set MQTT Topics” appears (Fig. 4). This section is used to define the MQTT topics where the converter will publish the data from BACnet and the topic that the converter will subscribes for writing the data to BACnet. - Page 25 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 25 of 34 Industrial Electronic Devices MQTT S UBSCRIBE Figure 4b: “Set MQTT Topics MQTT Subscribe” window The means of the fields are: In the field “Topic” the MQTT topic is defined; In the field “QoS”...
-
Page 26: Set Bacnet Access
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 26 of 34 Industrial Electronic Devices SET BACNET ACCESS: By Pressing the “Set BACnet Access” button from the main window for SW67938 (Fig. 2) the window “BACnet Set Access” appears (Fig. 5). The window is divided in two parts, the “BACnet in Read”... -
Page 27: Bacnet Ede File
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 27 of 34 Industrial Electronic Devices Is possible to insert directly the Unit (using its unique number) by compiling the “Selected BACnet Engineering Unit” field; or by selecting with the fields “Select the Type”... -
Page 28: Update Device
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 28 of 34 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 29 User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 29 of 34 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67938 device. Warning: If Fig.
-
Page 30: Template String: Definition Of Mqtt Payload
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 30 of 34 Industrial Electronic Devices TEMPLATE STRING: DEFINITION OF MQTT PAYLOAD In the section “Set Communication” of the SW67938, it is possible to define a Template string for the MQTT messages. The template is necessary in order to define the structure of the payload of the MQTT message and the info contained. -
Page 31: Mechanical Dimensions
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 31 of 34 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 9: Mechanical dimensions scheme for HD67938-xxx-B2 ADFweb.com S.r.l. -
Page 32: Ordering Informations
B: Modulbox 2M, 35mm DIN Rail mounting BACnet Type IP: BACnet/IP MSTP: BACnet MS/TP Device Family HD67938: BACnet Slave / MQTT - Converter Order Code: HD67938-IP-B2 BACnet/IP Slave / MQTT – Converter Order Code: HD67938-MSTP-B2 BACnet MS/TP Slave / MQTT – Converter ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –... -
Page 33: Disclaimer
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 33 of 34 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 34: Warranties And Technical Support
User Manual BACnet Slave / MQTT Document code: MN67938_ENG Revision 1.000 Page 34 of 34 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
