Industrial Electronic Devices
User Manual
Revision 1.000
English
Modbus Slave / MQTT - Converter
(Order Code: HD67934-x-B2)
For Website information:
www.adfweb.com?Product=HD67934-B2
For Price information:
www.adfweb.com?Price=HD67934-2-B2
www.adfweb.com?Price=HD67934-4-B2
Benefits and Main Features:
Very easy to configure
Power Supply 18...35V DC and 8...24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual Modbus Slave / MQTT
Document code: MN67934_ENG
For others MQTT products, see also the following links:
Converter MQTT to
www.adfweb.com?Product=HD67930
www.adfweb.com?Product=HD67931
www.adfweb.com?Product=HD67932
www.adfweb.com?Product=HD67933
www.adfweb.com?Product=HD67935
www.adfweb.com?Product=HD67936
www.adfweb.com?Product=HD67937
www.adfweb.com?Product=HD67938
www.adfweb.com?Product=HD67939
www.adfweb.com?Product=HD67940
www.adfweb.com?Product=HD67941
www.adfweb.com?Product=HD67942
www.adfweb.com?Product=HD67943
www.adfweb.com?Product=HD67944
www.adfweb.com?Product=HD67945
www.adfweb.com?Product=HD67946
www.adfweb.com?Product=HD67947
www.adfweb.com?Product=HD67948
www.adfweb.com?Product=HD67949
www.adfweb.com?Product=HD67950
www.adfweb.com?Product=HD67951
www.adfweb.com?Product=HD67952
www.adfweb.com?Product=HD67953
www.adfweb.com?Product=HD67954
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.001
Page 1 of 33
(Ethernet)
(M-Bus)
(Serial)
(Modbus Master)
(Modbus TCP Master)
(Modbus TCP Slave)
(BACnet Master)
(BACnet Slave)
(CAN)
(CANopen)
(DALI)
(DeviceNet Master)
(DeviceNet Slave)
(DMX)
(EtherNet/IP)
(J1939)
(KNX)
(NMEA 0183)
(NMEA 2000)
(PROFIBUS Master)
(PROFIBUS Slave)
(PROFINET)
(SNMP Manager)
(SNMP Agent)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADF Web HD67934-B2 Series
Summary of Contents for ADF Web HD67934-B2 Series
- Page 1 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 1 of 33 Industrial Electronic Devices User Manual Revision 1.000 English Modbus Slave / MQTT - Converter (Order Code: HD67934-x-B2) For Website information: For others MQTT products, see also the following links: www.adfweb.com?Product=HD67934-B2 Converter MQTT to www.adfweb.com?Product=HD67930...
-
Page 2: Table Of Contents
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 2 of 33 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 3 of 33 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 4 of 33 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 5 of 33 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67934-4-B2 ADFweb.com S.r.l. -
Page 6: Characteristics
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 6 of 33 Industrial Electronic Devices CHARACTERISTICS: The HD67934-B2 is a Modbus Slave / MQTT Converter. It allows the following characteristics: Electrical isolation between Ethernet and Modbus; Mountable on 35mm Rail DIN; Wide power supply input range: 18…35V DC and 8…24V AC;... -
Page 7: Power Supply
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 7 of 33 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax... -
Page 8: Function Modes
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 8 of 33 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... -
Page 9: Leds
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 9 of 33 Industrial Electronic Devices LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Rs485
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 10 of 33 Industrial Electronic Devices RS485: For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). Here some codes of cables: Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;... -
Page 11: Ethernet
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 11 of 33 Industrial Electronic Devices ETHERNET: The Ethernet port is used for programming the device and for MQTT communication. The Ethernet connection must be made using Connector2 of HD67934-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. -
Page 12: Use Of Compositor Sw67934
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 12 of 33 Industrial Electronic Devices USE OF COMPOSITOR SW67934: To configure the Converter, use the available software that runs with Windows called SW67934. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 13: New Configuration / Open Configuration
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 13 of 33 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “Modbus Slave / MQTT - Converter”... -
Page 14: Software Options
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 14 of 33 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 15 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 15 of 33 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 16: Set Communication
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 16 of 33 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67934 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in different sections in order to define the different parameters of the converter: Working Mode... - Page 17 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 17 of 33 Industrial Electronic Devices ORKING This section is used to define the working mode of MQTT side of the converter. It is possible to define: Sniffer: it is possible sniff a bus as a passive device. The converter will publish all the frames in the bus, using the message payload defined.
- Page 18 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 18 of 33 Industrial Electronic Devices MQTT: This section is used to define the main parameters of MQTT line. The means of the fields are: In the field “Server URL”...
- Page 19 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 19 of 33 Industrial Electronic Devices THERNET This section is used to define the general parameters of Ethernet. The means of the fields are: In the field “Ip Address”...
- Page 20 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 20 of 33 Industrial Electronic Devices If the field “Enable DHCP” is checked, the converter acts as DHCP Server for the Clients connected. If the option is enabled, in the fields “DHCP First IP Address”...
- Page 21 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 21 of 33 Industrial Electronic Devices TLS (T RANSPORT AYER ECURITY This section is used to define the parameters of TLS protocol. The means of the fields are: If the field “Enable TLS”...
-
Page 22: Mqtt Set Topic (Synchronous Mode)
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 22 of 33 Industrial Electronic Devices MQTT SET TOPIC (Asynchronous Mode): By Pressing the “MQTT Set Topic” button from the main window for SW67934 (Fig. 2) the window “Set MQTT Topics” appears (Fig. 4). This section is used to define the MQTT topics where the converter will publish the data from Modbus and the topic that the converter will subscribes for writing the data to Modbus. - Page 23 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 23 of 33 Industrial Electronic Devices MQTT S UBSCRIBE Figure 4b: “Set MQTT Topics MQTT Subscribe” window The means of the fields are: In the field “Topic” the MQTT topic is defined; In the field “QoS”...
-
Page 24: Mqtt Set Topic (Sniffer Mode)
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 24 of 33 Industrial Electronic Devices MQTT SET TOPIC (Sniffer Mode): By Pressing the “MQTT Set Topic” button from the main window for SW67934 (Fig. 2) the window “Set MQTT Topics” appears (Fig. 4). This section is used to define the MQTT topics where the converter will publish the data sniffed from. -
Page 25: Update Device
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 25 of 33 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 26 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 26 of 33 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67934 device. Warning: If Fig.
-
Page 27: Template String: Definition Of Mqtt Payload
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 27 of 33 Industrial Electronic Devices TEMPLATE STRING: DEFINITION OF MQTT PAYLOAD In the “Set MQTT Access” section, it is possible to define a Template string for the MQTT messages. The template is necessary in order to define the structure of the payload of the MQTT message and the info contained. -
Page 28: Modbus Map (Asyncronous Mode)
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 28 of 33 Industrial Electronic Devices MODBUS MAP (ASYNCHRONOUS MODE): On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps. Read with Input Register / Status Function not enabled Data in reading: Type... - Page 29 User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 29 of 33 Industrial Electronic Devices Read with Input Register / Status Function enabled Data in reading: Type Address Function Description Input Bytes 0-1 of internal array Input Register Input Bytes 2-3 of internal array Input Register Input Bytes 4-5 of internal array...
-
Page 30: Mechanical Dimensions
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 30 of 33 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67934-4-B2 ADFweb.com S.r.l. -
Page 31: Ordering Informations
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 31 of 33 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67934 – X – B 2 Connectors Type 2: Fixed Screw Terminal Enclosure Type B: Modulbox 4M, 35mm DIN Rail mounting... -
Page 32: Disclaimer
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 32 of 33 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 33: Warranties And Technical Support
User Manual Modbus Slave / MQTT Document code: MN67934_ENG Revision 1.001 Page 33 of 33 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
