RECEIVE NMEA 2000:

By pressing the "Receive NMEA
appears (Fig. 5).
Figure 5: "Receive NMEA 2000 Frames" window
The means of the fields of the table are:
In the field "PGN" the PGN of the NMEA 2000 message to receive is defined (in the NMEA 2000 protocol, the PGN is an identifier);
In the field "Source Address" the address of the device that sends the frame is defined.
If the field "Transport
If the field "Fast Packet" is checked, the frame will use the Fast Packet functions;
In the field "Start Byte" the starting byte to save on MQTT side is defined;
In the field "Num Bytes" the number of consecutive byte from the starting one is defined. For example, if the Start Byte is '20' and
Num Bytes is '10', it is possible to read the byte from 20 to 30;
If the field "Cancel Data" is checked, when the data is oldest of the time inserted in the "TimeOut Data", the converter sets "0xFF" in
the bytes of the internal memory array reserved for the PGN;
In the field "Mnemonic" the description for the frame is defined.
ADFweb.com S.r.l.
2000" button from the main window for SW67949 (Fig. 2) the window "Receive NMEA 2000 Frames"
Protocol" is checked, the frame can use transport protocol functions;
