EN
OPERATION GUIDELINES
Vacuum cleaner assembly
Always disconnect the plug out of the electrical outlet before assembling or removing accessories!
1. Insert the aluminium tube into the main body of the cleaner until you heard a "click" sound (Fig. 1). To remove the
tube, press the nozzle release button and pull away from the main body (Fig. 2).
Fig. 1
2. Insert the turbo nozzle into the aluminium tube until you hear a "click" sound (Fig. 3). To remove the turbo nozzle,
press the nozzle release button and pull away from the main body (Fig. 4).
You can insert the turbo nozzle to the main body as described above.
Fig. 3
46
Fig. 2
Fig. 4
VP6000
