The EMV3.1 Accessories

Test Strip Bottle
Blood Glucose Test Strip
Control Solution Bottle
Electrode
Strip Insert
Direction
Hand Hold
Area
Reaction Area
Blood Collection
Area
Lancing Device
Sliding barrel -
Pull on until it clicks
and then release to
enable lancing
device.
Trigger button-
Press the trigger
button to activate
the lancing device
AST
Lancing
Device Cap-
Use this
transparency
cap for AST
testing
Expiration
Date
Sleeve-
Hand Hold
Area
Hub-
Unscrew or
Recap the Cap.
Carrier-
Insert the lancet
into the carrier
Adjustable tip-
Select the
desired
penetration depth
