OneStream Programming Guide
1

Introduction

Please refer to the OneStream Hardware Installation Guide for instructions on the physical
installation of the unit. In order to program the OneStream unit it must be connected to a 10Mb/s
or 100Mb/s Local Area Network and you must have access to a PC connected to the same network.
If no Local Area Network is available the OneStream unit can be configured by connecting it to a PC
via a standard Ethernet Crossover cable.
All of the configuration options for the OneStream unit are controlled via a Web Configuration
Utility that can be accessed from any standard web browser on your PC. No special software needs
to be installed on the PC to access the Web Configuration Utility, however a OneStream Scanner
utility is available to assist in finding the IP Addresses of any OneStream units installed on your
Local Area Network. Refer to the following sections for more information.
2

Network Settings

The Network settings for the OneStream Unit can be configured in 2 ways – static assignment or
dynamic assignment. When the unit is powered on for the first time it will search for a DHCP Server
and request an IP Address (ensure that the Ethernet Cable is connected to the unit before
powering it on). If no DHCP Server is found then the unit will use its default IP Address,
192.168.0.1. This Static IP Address can be changed from the web configuration utility.
