OneStream GBRI Quick Start Guide
This guide gives a basic overview of installing and programming the OneStream GBRI to route calls
between PBX Trunk (S0) ports and GSM. For more information please refer to the OneStream
Hardware Installation Guide and OneStream Programming Guide which are both included
with the unit.

1 Hardware Installation

1.
Insert SIM Cards and attach Antennae:
2.
Take the bottom cover off by removing
the small screw at the bottom of the unit
and sliding the cover downwards
3.
Connect the Safety Earth
Ground
Version 1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OneStream GBRI and is the answer not in the manual?

Questions and answers

Related Manuals for Telecom FM OneStream GBRI

Summary of Contents for Telecom FM OneStream GBRI

  • Page 1: Hardware Installation

    OneStream GBRI Quick Start Guide Version 1 This guide gives a basic overview of installing and programming the OneStream GBRI to route calls between PBX Trunk (S0) ports and GSM. For more information please refer to the OneStream Hardware Installation Guide and OneStream Programming Guide which are both included with the unit.
  • Page 2 OneStream GBRI Quick Start Guide Replace the bottom cover by sliding it back upwards and replacing the screw. Connect the first TE port on the OneStream to an available Trunk (S0) Port on the PBX. Connect the power to the unit and wait for...
  • Page 3 OneStream GBRI Quick Start Guide 2 Programming By default: When OneStream starts up, it will try to find a DHCP Server to obtain an IP Address automatically. If it does not find a DHCP server, it will use its default IP Address of 192.168.0.1.
  • Page 4 OneStream GBRI Quick Start Guide Right-click the Local Area Connection icon and click Properties: Click on the Internet Protocol (TCP/IP) entry and click the Properties button. Click the Use the following IP address option and fill in the details as shown here: IP Address: 192.168.0.2...
  • Page 5 OneStream GBRI Quick Start Guide Editing the OneStream Programming Connect one end of a Crossover (X-Over) Ethernet Cable to the LAN port of the OneStream: Connect the other end of the Crossover Ethernet cable to the LAN port of your computer.
  • Page 6 OneStream GBRI Quick Start Guide To alter the routing to your requirements for Outbound GSM calls from the PBX, click the Edit icon next to the route named TE to NT and set the following options: • Change the Name of the route to TE to GSM •...
  • Page 7 OneStream GBRI Quick Start Guide To alter the routing to your requirements for Inbound GSM calls to the PBX, click the Edit icon next to the route named NT to TE and set the following options: • Change the Name of the route to GSM to TE •...
  • Page 8 OneStream GBRI Quick Start Guide The Routing table should now look like this: The OneStream is now ready for use.
