OneStream Programming Guide
4.5.1 Audio Settings
Tone Selection
Select the country that the OneStream unit is being installed into from the drop-down list. This will
set the various tones the system generates (e.g. Dialtone) to emulate those of the local Telephone
providers.
Gain Control
Automatic – All interfaces will use default gain levels. This is the recommended setting/
Manual – After manual is selected gain controls will be available for any Groups containing
physical interfaces.
GSM Dial Voice Prompt
If enabled, when a call is routed to one of the GSM modules the caller will hear the message
"Please wait while your call is connected".
DTMF Detection Options
Controls the DTMF detection parameters:
DTMF On Time – set the minimum length of time (in ms) that DTMF frequencies must be
detected for before it is considered to be a valid DTMF tone
DTMF Off Time – set the minimum length of time (in ms) that no DTMF frequencies should
be detected for before it is considered to be a new DTMF tone
Save Audio Settings – click the button to apply the audio settings.
4.5.2 SIP Settings
RTP Timeout
A SIP call will be terminated if there is no RTP activity for the set number of seconds (and the call
is not on hold). Default is 10 seconds. A setting of 0 indicates no timeout.
Hold Timeout
A SIP call which is on Hold will be terminated if there is no RTP activity for the set number of
seconds. Default is 60 seconds. A setting of 0 indicates no timeout.
Register Expiry
Set the duration of SIP registrations. A new Register packet will be sent or expected within the set
number of seconds. Default is 120 seconds.
Registrar Timeout
Set the number of seconds to wait for a response to a Register packet. If no response is received
within the set number of seconds the SIP registrar will be considered to be unavailable. Default is
20 seconds.
RTP Port Range
Specify the range of ports that the OneStream can use for carrying RTP audio. Default is 10000-
20000.
47
