Technical Reference for
ZyXEL omni.net series
omni.net LCD
omni.net LCD+M
omni.net Plus
omni.net D
ISDN Terminal Adapters
ZyXEL
T
I
A
S
OTAL
NTERNET
CCESS
OLUTIONS
ZyXEL Communications Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the omni.net LCD+M and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications omni.net LCD+M

Summary of Contents for ZyXEL Communications omni.net LCD+M

  • Page 1 Technical Reference for ZyXEL omni.net series omni.net LCD omni.net LCD+M omni.net Plus omni.net D ISDN Terminal Adapters ZyXEL OTAL NTERNET CCESS OLUTIONS ZyXEL Communications Corporation...
  • Page 2 ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer: ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.

  • Page 3: Limited Warranty

    Limited Warranty ZyXEL omni.net series ISDN Terminal Adapters Conditions of ZyXEL Limited Warranty: ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two (2) years from the date of purchase. During the warranty period, and upon proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials, ZyXEL will, at its discretion, repair or replace the defective products or components without charge for either parts or labor, and to whatever extent it shall deem necessary to restore the product or...

  • Page 5: Table Of Contents

    PART I INTRODUCTION CHAPTER 1 INTRODUCTION Key Features... 1-1 Speed and Compatibility... 1-1 Intelligent Features... 1-2 Specifications ... 1-2 Key Features Summary... 1-3 Installing Your ZyXEL omni.net ISDN TA ... 1-4 CHAPTER 2 ® USING ZYXEL ISDN CONFIGURATION MANAGER About ZyXEL ISDN Configuration Manager ... 2-1 Start using ZyXEL ISDN Configuration Manager...
  • Page 6 CHAPTER 4 ISDN COMMUNICATION BASICS Understanding AT Commands ...4-1 Examples of AT Commands ...4-1 Additional AT Command Set for Internal Fax/Modem (for omni.net LCD+M only)...4-2 Supported AT Command Types...4-3 Quick Tips when Issuing AT Commands...4-3 Outgoing Calls...4-4 Dialing Data Calls ...4-4 Dial Out Voice Calls (for ZyXEL omni.net LCD/LCD+M//Plus) ...4-4...
  • Page 7 Answering a Call Using MSN ... 4-8 Data Over Speech Channel (for ZyXEL omni.net LCD/LCD+M/Plus)... 4-10 Best-effort Call Answering (for ZyXEL omni.net LCD/LCD+M/Plus)... 4-10 Ambiguity Resolution Switch for Voice Calls (for omni.net LCD/LCD+M/Plus)... 4-10 PART III VOICE FEATURES CHAPTER 5 SUPPLEMENTARY SERVICE (FOR ZYXEL OMNI.NET LCD/LCD+M/PLUS) To Implement the Supplementary Services ...
  • Page 8 Technical Reference for ZyXEL omni.net series Call Waiting...6-3 Receiving a Second Call...6-3 Call Broker ...6-4 Call Reject ...6-5 To disconnect caller C and switch back to caller B...6-5 Call Transfer ...6-5 Three-Way Conference Call...6-6 Conference Call (1 local and 2 remote call)...6-6 Conference Call (2 local and 1 remote call)...6-6 Last Number Redial ...6-7 Quick Dial ...6-7...
  • Page 9 Modifying the User Passwords... 8-17 Non-password Auto Call Back Function ... 8-17 PART V FAX/MODEM FUNCTION CHAPTER 9 INTERNAL FAX/MODEM FUNCTION (FOR ZYXEL OMNI.NET LCD+M ONLY) Internal Fax/Modem Basics ... 9-1 Modem Standards and Speeds... 9-1 MNP Protocols ... 9-2 Xmodem, Ymodem, and Zmodem...
  • Page 10 Technical Reference for ZyXEL omni.net series Dialing Out for Internal Fax/Modem ...9-4 Manually Switching Communication Modes ...9-4 Incoming Calls for internal Fax/modem...9-5 LCD Panel When Internal Fax/Modem Operation ...9-6 Control the Speaker of Internal Fax/Modem...9-6 Control Data Compression ...9-7 Fax Operation...9-7 Fax Command Sets...9-8 Internal Fax/Modem AT Command Set Summary ...9-8 PART VI DIAGNOSTICS &...
  • Page 11 Basic S-Registers 'ATSn=x' ...B-5 Extended S-Registers "ATSn=x" ...B-6 'ATXn' Result Code Option Table...B-21 Result Code for Internal Fax/Modem (for ZyXEL omni.net LCD+M only)...B-23 Result Code Chart Symbol Reference...B-25 Result Code Field Descriptions ...B-26 Connect Strings for Error Corrected Connections ...B-27...
  • Page 12 Technical Reference for ZyXEL omni.net series APPENDIX D SERIAL PORT INTERFACE EIA-232D 25 Pin Serial Port Interface ...D-1 Async. Hardware Flow Control Cable Connection...D-2...
  • Page 13 At Commands for numberical/verbose result code... 4-3 Table 22. Manual Switch AT Command For ZyXEL omni.net LCD/Plus ... 4-6 Table 23. Manual Switch AT Command For ZyXEL omni.net LCD+M ... 4-6 Table 24. AT Command for Placing a Data Call ... 4-7 Table 25.
  • Page 14 Technical Reference for ZyXEL omni.net series Table 30. Global Call AT Command...4-12 Table 31. Call Waiting S Register...5-2 Table 32. Call Forwarding AT Command...5-6 Table 33. Flash Key Commands...6-2 Table 34. Call Waiting AT Commands ...6-3 Table 35. Related AT Command for Async to Sync Conversion...7-2 Table 36.
  • Page 15 Table 63. EPA-Capture AT Commands (1) ... 10-6 Table 64. EPA-Capture AT Commands (2) ... 10-6 Table 65. EPA-Analyze AT Commands... 10-7 Table 66. display control key functions... 10-7 Table 67. Description of Basic 'AT' Command Set ...A-3 Table 68. Basic 'AT' Command Set...A-10 Table 69.
  • Page 17 Figure 1. ZyXEL ISDN Configuration Manager icon... 2-2 Figure 2. The Com Port Setting of ZyXEL ISDN Configuration Mangaer ... 2-3 Figure 3. ZyXEL ISDN Configuration Manager Main Menu... 2-4 Figure 4. Configuration Settings ... 2-5 Figure 5. LCD Front Panel ... 3-2 Figure 6.
  • Page 18 ZyXEL omni.net LCD is the first ISDN terminal adapter in the communication industry to provide a control panel equipped with a 20 x 2 LCD display and four menu keys for easy configuration and detailed status monitoring. ZyXEL omni.net LCD+M has not only the LCD display and four operation keys, but also includes xviii...

  • Page 19: How To Use This Manual

    “ZyXEL omni.net LCD/LCD+M” represents the ZyXEL omni.net LCD and the ZyXEL omni.net LCD+M models. “ZyXEL omni.net Plus/D” represents the “ZyXEL omni.net Plus” and the “ZyXEL omni.net D” models. Otherwise, the model will be described specifically if the features and the instructions of the device can only be applied to that single model.
  • Page 21 Part I Introduction...

  • Page 23: Introduction

    This chapter introduces the features and specifications for the ZyXEL omni.net LCD/LCD+M/Plus/D, and provides instructions for installing your ZyXEL omni.net ISDN TA Key Features Speed and Compatibility Plug and Play support for Win95/98/NT environment. Full compatibility with both ISDN and remote PSTN via ISDN. 112Kbps/128Kbps channel bundling: MLP, and Multilink PPP(RFC1990).

  • Page 24: Intelligent Features

    RJ-45 for S/T interface DTE Interface DB-25 connector Weight omni.net LCD: 448 g; omni.net LCD+M: 557g omni.net Plus: 379 g; omni.net D: 358 g Dimensions omni.net LCD/LCD+M: 192mm (W) x 42.5mm (H) x 145.6mm(L) omni.net Plus/D: 183mm (W) x 36.5mm (H) x 135.0mm(L)

  • Page 25: Key Features Summary

    PPP, V.120, PPP, V.120, V.110, X.75 V.110, X.75 PPP-MP, MLP PPP-MP, MLP 8 LED 10 LED LCD Panel 20x2 LCD Panel 460.8Kbps 460.8Kbps omni.net LCD+M 64Kbps PPP, V.120, V.110, X.75 PPP-MP, MLP 8 LED LCD Panel 20x2 LCD Panel 460.8Kbps...

  • Page 26: Installing Your Zyxel Omni.net Isdn Ta

    Technical Reference for ZyXEL omni.net series Installing Your ZyXEL omni.net ISDN TA For detailed instructions on how to install and configure your ZyXEL omni.net ISDN TA with the ZyXEL ISDN Configuration Manager (ZyXEL ICM), please refer to the Quick Start Guide particular to your device that comes with your omni.net package.

  • Page 27: Using Zyxel Isdn Configuration Manager

    ® Using ZyXEL ISDN Configuration Manager This chapter shows you how to use the ZyXEL ISDN Configuration Manager (ICM). About ZyXEL ISDN Configuration Manager The ZyXEL ISDN Configuration Manager is a Graphical User Interface (GUI) program that runs on Windows 95/98/NT operating systems. You can control and set up your ZyXEL omni.net ISDN TA either by using a traditional terminal program where you need to program AT commands, or by running this user friendly ZyXEL ISDN Configuration Manager.

  • Page 28: Start Using Zyxel Isdn Configuration Manager

    Technical Reference for ZyXEL omni.net series Start using ZyXEL ISDN Configuration Manager Follow these steps to use the ZyXEL ISDN Configuration Manager: Step 1. To display the ZyXEL ISDN Configuration Manager main menu Double-click on the ZyXEL ISDN Configuration Manager icon to start the Configuration Manager. Figure 1.
  • Page 29 Step 2. After checking all active serial communication ports, the ZyXEL ISDN Configuration Manager automatically detects which communication port is connected to your ZyXEL omni.net ISDN TA. If the ZyXEL ISDN Configuration Manager can not find your ZyXEL omni.net ISDN TA, it will prompt you with the Port Setup dialog-box, as shown in the following illustration: Figure 2.
  • Page 30 Technical Reference for ZyXEL omni.net series Setp 3. ZyXEL ISDN Configuration Manager Main Menu Figure 3. ZyXEL ISDN Configuration Manager Main Menu Loopback Test Firmware Upgrade Monitor Phone Services Subscriber Number Configuration Model name of the ZyXEL omni.net ISDN TA device installed in your computer.
  • Page 31 Step 4. Configuration Settings Figure 4. Configuration Settings Technical Reference for ZyXEL omni.net series PPP Settings Keep Connection Alive Call Bumping Bandwidth On Demand Outgoing Protocol Control Multilink or Multiple link STAC or V.42bis Compress Data rate...

  • Page 32: Configuring Isdn Parameters

    Technical Reference for ZyXEL omni.net series Follow the guidelines in the table below designed to assist you in configuring the ISDN parameters of your ZyXEL omni.net ISDN TA. Configuring ISDN Parameters ISDN Parameter Outgoing Protocol Sets the calling protocol for the your ZyXEL omni.net ISDN TA. The Control protocol selected should match the protocol in use by the device or network your ISDN TA is calling.

  • Page 33: Lcd Panel Operation (For Zyxel Omni.net Lcd/Lcd+M)

    ZyXEL omni.net LCD is the first ISDN TA in the industry to provide a control panel equipped with a 20 x 2 LCD display and four menu keys for easy configuration and detailed status monitoring. ZyXEL omni.net LCD+M has not only a LCD display and four operation keys, but also has included a built-in 56K modem.

  • Page 34: Lcd Panel Functions

    Technical Reference for ZyXEL omni.net series Moreover to help filter undesired phone calls, your omni.net LCD supports Caller ID when connected to a caller ID box. The LCD panel displays the calling party's phone number. The LCD on ZyXEL omni.net LCD/LCD+M is as below: Firmware Version Model Name omni.net LCD...

  • Page 35: Lcd Panel Operation Keys

    LCD Panel Operation Keys Next menu option selection Right key: Next item selection (shift right one digit) Previous menu option selection Left key: Previous item selection (shift left one digit) Cancel Up key: Return to previous menu Quit Enter new setting Down key: Save new setting Shift down to next sub-menu...

  • Page 36: Idle Screen

    Technical Reference for ZyXEL omni.net series The following screens represent the LCD display as seen on your ZyXEL omni.net LCD/LCD+M front panel, for various status of ISDN TA. Idle Screen LCD Display omni.net LCD Omni.net LCD V 1.00 V 1.00 02-03-1998 08:12 02-03-1998...

  • Page 37: Dial In Log

    Dial In Log LCD Display Dial In Log << Dial In Log >> sub-menu #01: TEL1 00:01:02 Fm:035783942 TEL1 00:01:02 035783942 02-03-1998 #01: TEL1 00:01:02 09:32 02-03-1998 09:32 Table 10. Dial In Log Stored Phone List LCD Display Stored Phone List sub-menu <<Stored Phone List>>...

  • Page 38: Dial Out Log

    Technical Reference for ZyXEL omni.net series Dial Out Log LCD Display Dial Out Log << Dial Out Log >> sub-menu #01: TEL1 $102 To:5783942 TEL1 $102 5783942 #01: TEL1 00:02:06 00:02:06 To:5783942 02-02-1998 #01: TEL1 00:01:02 09:32 02-02-1998 09:32 Table 12. Dial Out Log Description : record number nn (nn=01-20) of an outgoing call...

  • Page 39: Active Status

    Active Status When the omni.net LCD is idle, an incoming call or outgoing call will cause it to auto-change the screen to active status, as shown in the examples below: B1 TEL2 Fm:035783942 One incoming call has been answered. (One B-channel active) B2 Idle B1 Analog Fm:5783942 One incoming call has NOT been answered.

  • Page 40: Clock Options

    Technical Reference for ZyXEL omni.net series Clock Options Display Clock Operation LCD Display Omni.net LCD V 1.00 02-02-1998 << Clock Options >> 1. press button. << Set Clock >> 2. press button. Set Clock 3. press button. Year 1998 Set Clock 4.

  • Page 41: Update Clock

    Update Clock Operation LCD Display Set Clock Year 1998 Set Clock 1. press button. Year _ Set Clock 2. press Year _ button. Set Clock 3. press button. Year 1_ Set Clock 4. repeat steps 2 and 3. Year 1998 <<...

  • Page 42: Set Display Mode

    Technical Reference for ZyXEL omni.net series Set Display Mode Operation LCD Display << Clock Options >> Set Clock 1. press button. Year 1998 Set Display Mode 2. press [ 24Hr button. Set Display Mode 3. press button. = 24Hr Set Display Mode 4.

  • Page 43: Dial In Log Options

    Dial In Log Options Dial In Log Records Operation LCD Display Omni.net LCD V 1.00 02-03-1998 << Dial In Log >> 1. press button. #01: TEL1 00:01:02 2. press button. Fm:035783942 #02: V120 00:02:06 3. press Fm:035774848 button. << Dial In Log >> 4.

  • Page 44: Stored Phone List Options

    Technical Reference for ZyXEL omni.net series Stored Phone List Options Stored Phone List Records Operation LCD Display omni.net LCD V 1.00 02-03-1998 <<Stored Phone List>> 1. Press button. Stored Phone List 2. press button. #00=035712121 Stored Phone List 3. press #01=035783942 button.

  • Page 45: Dial Out Log Options

    Dial Out Log Options Records of Outgoing Calls Operation LCD Display omni.net LCD V 1.00 02-03-1998 << Dial Out Log >> 1. Press button. #01: TEL1 2. press button. To:5783942 #02: V120 00:02:06 3. press To:5712121 button. << Dial Out Log >> 4.

  • Page 47: Part Ii Isdn Function

    Part II ISDN Function...

  • Page 49: Isdn Communication Basics

    ISDN Communication Basics This chapter covers how to initiate and receive calls over digital lines using your ZyXEL omni.net ISDN TA. Understanding AT Commands AT commands are used to configure and control the omni.net by typing the command statements at the computer or terminal keyboard.

  • Page 50: Additional At Command Set For Internal Fax/Modem (For Omni.net Lcd+M Only)

    (Refer to your communications software manual.) Additional AT Command Set for Internal Fax/Modem (for ZyXEL omni.net LCD+M only) Beside the AT commands supported by omni.net LCD, there are additional AT commands for internal fax/modem usage to control speaker (ATMn and ATLn), data compression (AT&Kn),...

  • Page 51: Supported At Command Types

    Supported AT Command Types Type of AT Command Supported Basic AT (Hayes compatible) Basic AT$ (on line help) Extended AT& Extended AT* command S-Register command S-Register bit-mapped command S-Register inquiry command Table 20. Supported AT Command Types Quick Tips when Issuing AT Commands To execute an AT command, press the <ENTER>...

  • Page 52: Outgoing Calls

    Dialing Out using internal Fax/modem (for ZyXEL omni.net LCD+M) Using the “M” command following the “ATD” will tell your omni.net LCD+M to automatically switch calls to the internal fax/modem once dialing is complete. & Type: ATDM17146930762<enter> (Make a voice call on analog port 2) Dialing Out Using ISDN Mode Optional Speech Bearer Service Your omni.net supports ISDN data utilizing Speech Bearer Service.
  • Page 53 Technical Reference for ZyXEL omni.net series & To enable Speech Bearer Service, type: ATS83.7=1<enter> & To disable this function, type: ATS83.7=0 <enter>...

  • Page 54: Manually Switching Communication Mode (For Zyxel Omni.net Lcd/Lcd+M/Plus)

    ATD, ATDT and ATDP are the same as ATDA Table 23. Manual Switch AT Command For ZyXEL omni.net LCD+M (For more information on ZyXEL omni.net LCD+M, please refer to Chapter 9 Internal Fax/Modem Function) The factory default setting is [AT&O2] that instructs the omni.net to select ISDN data mode when...

  • Page 55: Placing A Data Call

    Placing a Data Call While placing a voice call can be as simple as dialing out with your analog phone, initiating a data call requires prior selection of a proper B-channel protocol. Here are some simple commands that will be useful when placing a call. The omni.net has the capability to automatically detect the B-channel protocol (V.120, X.75, or PPP) used by the answer site.

  • Page 56: Answering A Call Using Msn

    Assigns MSN 's' for ISDN data, protocol auto-detection &ZI6=s Assigns MSN 's', phone number for Phone 2 (for omni.net LCD/Plus) and modem (for omni.net LCD+M only) &ZI7=s Assigns MSN 's', phone number for Phone 1 (for omni.net LCD/ LCD+M/Plus) Table 26. AT Command for answering a call using MSN [AT&ZI?] can be used to display the MSN numbers.
  • Page 57 If an incoming SETUP message is offered with addressing information (i.e. the appropriate part of the called_party_number), this address will be compared with the MSN numbers assigned by the [AT&ZIn=s] commands. The call will be accepted using the specific protocol, if the assigned number of this protocol matches the received called party number.

  • Page 58: Data Over Speech Channel (For Zyxel Omni.net Lcd/Lcd+M/Plus)

    Technical Reference for ZyXEL omni.net series Data Over Speech Channel (for ZyXEL omni.net LCD/LCD+M/Plus) If you are expecting ISDN data calls through the Speech (Voice) channel, you need to setup MSN for that purpose. To the omni.net, if no MSN entries are found in MSN ISDN data lists, all Speech (Voice) calls will be sent to either Phone 1 or Phone 2.
  • Page 59 Unassigned Unassigned Table 29. Scenarios of an Incoming Voice Call Technical Reference for ZyXEL omni.net series Description Phone 1 has the higher priority. Phone 2 and modem (for omni.net LCD+M only) has the higher priority. Outcome S120.2 AT&Ln Phone (Default=0)
  • Page 60 Technical Reference for ZyXEL omni.net series The default MSN sub-address (or EAZ) for 1TR6 (Old German ISDN) of the a/b adapters are as follows: & Phone 1: EAZ = 4 (&ZI7=4) & Phone 2: EAZ = 3 (&ZI6=3) A global call is an inbound voice call with no destination phone number (Called-Party-Number) which may happen on some switches when the calling site is on the PSTN (analog telephone).

  • Page 61: Part Iii Voice Features

    Part III Voice Features...

  • Page 63: Supplementary Service (For Zyxel Omni.net Lcd/Lcd+M/Plus)

    (for ZyXEL omni.net LCD/LCD+M/Plus) Supplementary services such as call waiting, caller ID, … are generally available from your telecommunications provider. The omni.net LCD/LCD+M/Plus supports all of the following services: Caller ID Call Waiting Call Hold/Retrieve 3-Way Conference Multiple Subscriber Number (MSN) Sub-address Advice of Charge Supplementary services can be ordered from your local telecommunications provider.

  • Page 64: Call Waiting

    Technical Reference for ZyXEL omni.net series can invoke all the supplementary services by using a single key on your telephone keypad: the Flash key. To assign the flash key to enable supplementary service, issue the command [ATS120.7=1&W0Z0]. Call Waiting Call waiting allows you to put a call on hold while you answer another incoming call on the same phone (directory) number.

  • Page 65: Switch Back And Forth Between Two Callers

    Technical Reference for ZyXEL omni.net series Switch back and forth between two callers After using the call waiting option to answer a second incoming call, pressing the Flash key allows you to switch back and forth between caller B and C by putting either one on hold. Hang-up your current call before answering an incoming call Step 1.

  • Page 66: Three Way Conferencing

    Technical Reference for ZyXEL omni.net series Three Way Conferencing The three way conferencing feature allows you to add another party to an existing call, and gives you additional flexibility in selecting which call to drop at closure. You first need to subscribe this service from your telephone company. Then, issue the command [ATS120.7=1&W0Z0] that will assign the Flash key to supplementary service.

  • Page 67: Canceling The Conference Call (For Dss1 Switch Only)

    Technical Reference for ZyXEL omni.net series Canceling the conference call (for DSS1 switch only) When you wish to cancel the current conference call, simply press the Flash key. Dropping the last call added to the 3-way conference call (USA only) During a three way conference call, when you are ready to close with caller C, simply press the flash key.

  • Page 68: Call Forwarding

    Activate call forwarding on DSS1 switch Call forwarding busy (CFB) Call forwarding unconditional (CFU) Call forwarding no-reply (CFNR) All services ISDN data (unrestricted digital) POTS port (phone B) only or modem (for omni.net LCD+M only) Deactivate call forwarding on DSS1 switch...

  • Page 69: Reminder Ring (Usa Ni-1 & Dms-100 Switch)

    connected to a POTS port in order to activate or deactivate the CFV function. In most cases, dialing [*73<forwarded_number>] will activate CFV and dialing [*73] will disable it. Please check with your telecommunications provider first. In addition, CFV can be controlled by typing the following AT commands: ATCF<forwarded-number>: activate call forwarding to the designated number.
  • Page 70 Technical Reference for ZyXEL omni.net series Step 3. After you hear the ring signal, hang-up the phone without waiting for the second party to answer.

  • Page 71: Feature Phone Operation (For Omni.net Lcd/Lcd+M/Plus)

    (for omni.net LCD/LCD+M/Plus) The omni.net LCD/LCD+M/Plus supports ZyXEL's powerful and advanced feature phone operation. By connecting to the analog ports, you can get the benefits of analog phone services, plus additional features over your ISDN line, including: InterCom Call Waiting Call Hold/Retrieve Call History The Flash Key...

  • Page 72: Flash Key Commands

    Technical Reference for ZyXEL omni.net series Flash Key Commands Feature Phone Flash Key operation Commands Hold/Release/Cancel Press the Flash Press the Flash Call Waiting key and 0 Press the Flash InterCom key and 2 Three-Way Press the Flash Conference key and 3 Press the Flash Call Reject key and 5...

  • Page 73: Call Waiting

    Please follow the instructions below to operate the InterCom: Step 1. Pick up the telephone handset. Step 2. Press the Flash key, the push 2 on the phone keypad. Step 3. The other local phone will start to ring. Call Waiting The Call Waiting feature enables you to place a call on hold by pressing the Flash key.

  • Page 74: Call Broker

    Technical Reference for ZyXEL omni.net series NOTE: 1: If you disable the call waiting function (S79.2=0 or S79.3=0), the second incoming call will be blocked. 2: If you configure the POTS port for Modem/Fax connection (S79.4=1 or S79.5=1), the call waiting feature of the respective POTS port will be always disabled.

  • Page 75: Call Reject

    Repeat steps 1 and 2 above to switch back and forth between callers B and C. Call Reject The call reject option allows you to disconnect an active call and return to a call that is on hold without having to hang up your handset. To disconnect caller C and switch back to caller B Pressing the Flash key and 5 to will automatically switch back to caller B while disconnecting caller C.

  • Page 76: Three-Way Conference Call

    Technical Reference for ZyXEL omni.net series Three-Way Conference Call The conference call feature can be used in two ways: To connect 2 local parties (2 phones connected to the two POTS ports of you omni.net) to a remote party (1 dial-out number.) To connect one local party (1 phone connected to POTS port 1 or 2 of your omni.net) to 2 two remote parties (2 dial-out numbers.)

  • Page 77: Last Number Redial

    Last Number Redial This functions allows you to redial the last number called on POTS port Phone 1 and 2, even after the omni.net has been powered off and on again. The last numbers dialed on Phone 1 and 2 are stored in Non-Volatile RAM (NVRAM) at locations [AT&Z38] and [AT&Z3]9 respectively.

  • Page 79: Part Iv Data Function

    Part IV Data Function...

  • Page 81: Point-To-Point Protocol (Ppp)

    Point-to-Point Protocol (PPP) Introduction to PPP Point-To-Point Protocol (PPP) is designed for simple links, which transport packets between two peers. These links provide full-duplex simultaneous bi-directional operation, and are assumed to deliver packets in order. PPP is intended to provide a common solution for easy connection for a wide variety of hosts, bridges and routers.

  • Page 82: Feature List

    Technical Reference for ZyXEL omni.net series Data will be transmitted only when the link is in the open phase. Negotiation details are described in RFC1661. Feature List Async to Sync Conversion PPP uses HDLC-like framing as encapsulation, which can be bit-oriented or character-oriented. Most ISDN routers use bit-oriented HDLC framing, also known as synchronous transmission.

  • Page 83: Compression Control Protocol (Ccp)

    in hashed form by CHAP. Sometimes CHAP can not be supported by the ISP. You may set [S87.2=1] to use PAP only. If you do not want to do authentication at all, set [S118.3=1] to disable the conversion. CHAP is described in RFC1994 and PAP is described in RFC1334. The only hash method supported by CHAP is MD5;...

  • Page 84: Multilink Ppp

    Technical Reference for ZyXEL omni.net series Compression Control AT Commands AT&K00 AT&K44 Table 37. Compression Control AT Commands Multilink PPP There are two B channels in basic rate ISDN. This offers the possibility of opening multiple simultaneous channels between systems giving users additional bandwidth on demand. Multilink PPP is a method for bundling both B-channels into one PPP link for higher throughput.
  • Page 85 under calculation. In other words, the add/persist time is calculated from the time when the traffic is above the add-threshold whether or not the phone is on-hook or off-hook. However, it will not dial until the phone has been on-hook for 10 seconds. Call bumping works for both client (dialing) side and server (answering) side.

  • Page 86: Bandwidth On Demand (Bod)

    Technical Reference for ZyXEL omni.net series Bandwidth On Demand (BOD) The function of Bandwidth On Demand (BOD) will monitor the traffic on ISDN links while in Multilink PPP mode. If there is light traffic on the link, one of the channels will be dropped automatically.
  • Page 87 The second directory number is not necessary any more. The BACP/BAP is supported on the client side only, and the server side of BACP/BAP will be implemented in an upcoming release. BACP/BAP AT Commands ATBP0 Disable BACP/BAP negotiation. ATBP1 Enable BACP/BAP negotiation (default). Table 41.
  • Page 89 V.110, V.120, X.75 and Synchronous Mode This chapter describes how to set-up and configure your omni.net ISDN TA with the V.110, V.120, and X.75 protocols. The following table summarizes the specifications of those ISDN protocols. Synchronous Transparent Layer 1 None Layer 2 None Layer 3...

  • Page 90: About V.110, V.120 And X.75 Isdn Protocols

    Technical Reference for ZyXEL omni.net series About V.110, V.120 and X.75 ISDN Protocols ISDN Protocols V.110 V.110 is most popular in Japan. V.120 V.120 is most commonly used in the U.S.A. X.75 X.75 was originally designed for packet-switched signaling systems in public networks to provide data transmission services.

  • Page 91: V.110 Outgoing Protocol

    V.110 Outgoing Protocol Use the following commands to configure V.110 outgoing calls. AT Command ATB10 User rate follows DTE speed (see note below). ATB13 User rate = 2400bps ATB14 User rate = 4800bps ATB15 User rate = 9600bps ATB16 User rate = 14400bps ATB17 User rate = 19200bps ATB18...

  • Page 92: V.120 Outgoing Protocol

    Technical Reference for ZyXEL omni.net series V.120 Outgoing Protocol Some switches transmit all network signals through the D-channel (out-of-band signaling), allowing both B-channels to be used exclusively for your communication purposes. This allows for throughput of 64Kbps per channel. However, not all switches support out-of-band signaling at this time. For switches that do not support out-of-band signaling, network signals are transmitted through the B-channels.

  • Page 93: X.75 Outgoing Protocol

    X.75 Outgoing Protocol The X.75 protocol can be chosen using the following AT commands: AT Command ATB00 X.75 with transparent layer 3. ATB01 X.75 with T.70 NL. The ATB0x commands not only specify the outgoing protocol, but also set the default layer 3 for an incoming X.75 call without layer 3 information.
  • Page 94 Technical Reference for ZyXEL omni.net series NOTE: The omni.net LCD/LCD+M does not support network independent clock compensation. The synchronous timing source must be supplied by the omni.net LCD/LCD+M , which is phase locked to the network synchronous clock. When in V.25bis command mode, the omni.net LCD/LCD+M supports the bit-oriented HDLC (High-Level Link Control) synchronous protocol which most synchronous communication links use.

  • Page 95: Making V.120 And X.75 Bundled Calls

    Making V.120 and X.75 Bundled Calls Speeds of 128Kbps BRI ISDN consists of three (2B+D) logical channels. Each B-channel can be used independently for a dial-up connection running at 56Kbps or 64Kbps (Kbps = Kilo (1000) bits per second). The two B-channels can be used together for a single data connection to provide 112K (with In-Band Signaling) or 128K (when Out-of-Band Signaling is used).
  • Page 96 Technical Reference for ZyXEL omni.net series available for more flexibility, as shown below: AT&J0 Disables B-channel bundling. AT&J1 Enables B-channel bundling in answer mode only. AT&J2 Enables B-channel bundling in call mode only. AT&J3 Enables B-channel bundling in both call and answer modes. Once this is done, the [ATD] command will generate two consecutive SETUP messages to invoke bundle initiation.

  • Page 97: X.75 Bundled Call

    X.75 Bundled Call A bundle connection is initiated at the calling site by sending two consecutive SETUP messages to the network. The two SETUP messages are all the same except for the Call Reference values. [AT&Jn] can be used for bundle configuration as follows: AT Command AT&J0 Disables B-channel bundling.

  • Page 98: Dialing Pre-Stored Phone Numbers

    Technical Reference for ZyXEL omni.net series Dialing Pre-stored Phone Numbers The 40 phone numbers stored in the NVRAM can also be used to place a bundled call with V.120 or X.75, by using the [ATDSn] command: ATDSn n=0-39 Dial the (n)th phone number twice for both bundle connections. ATDSn+ n=0-38 Dial the (n)th phone number for the first connection and dial the (n+1)th phone...
  • Page 99 Technical Reference for ZyXEL omni.net series serial port unsuitable for bundle applications. A special I/O card on the computer side is required in this situation. 8-11...

  • Page 100: Error Correction And Data Compression With V.120

    Technical Reference for ZyXEL omni.net series Error Correction and Data Compression with V.120 With V.120, the default setting is for LAPD error correction only. No data compression will be negotiated unless V.42bis is enabled by setting [AT&K44]. With the &K44 setting, the omni.net will try to connect using V.42bis data compression. If the remote device does not support V.42, then LAPD error correction will be used.

  • Page 101: Selecting V.120 For European Isdn (Dss1)

    It takes about 2 seconds for the calling ISDN TA to send XID and wait until time out. If you know in advance that the called site has no V.42bis capability, it is advisable to issue the AT&K00 command beforehand in order to get a quick connection. Although not defined in X.75, XID frame is based on the encoding in ISO Standard 8885 and is used in V.42/V.42bis.
  • Page 102 Technical Reference for ZyXEL omni.net series password for matching with the local omni.net pre-stored password list. With a Type 2 connection, the remote terminal will be prompted to enter the password at the initial connection and the local omni.net will match the entered password with the pre-stored password list.
  • Page 103 The three levels of security used in conjunction with the security types are described in the following table. Level 1 Password Check CPN Check OK and S119.6=0 CPN Check OK and S119.6=1 nmatched CPN not Available [AT*G1] for Type 1 security AT Commands [AT*G3] for Type 2 security Level 1 security...

  • Page 104: Setting And Modifying Passwords

    Technical Reference for ZyXEL omni.net series Setting and Modifying Passwords Up to 40 user passwords can be defined using the [AT*Hn] command, where 'n' represents the index to the entry (n=0-39). The corresponding 40 callback numbers are defined by [AT&Zn=xxx] command, where 'n' represents the index to the entry, and 'xxx' represents the assigned callback phone number.

  • Page 105: Modifying The User Passwords

    Modifying the User Passwords Use command [AT*Hn] to modify the "n"th user password (n=0-39). The system will ask you to enter the supervisory password first and then the user password you want to modify. Use the command [AT*V] to list the 40 user passwords and the supervisor password on screen for viewing. Non-password Auto Call Back Function In addition to the standard modem-like security functions described in the previous section, the omni.net provides another simpler call back function that does not require any password check.
  • Page 106 Technical Reference for ZyXEL omni.net series AT*VC Password: (Enter new supervisory password) ******** 8-18...

  • Page 107: Part V Fax/Modem Function

    Part V Fax/Modem Function...

  • Page 109: Internal Fax/Modem Function (For Zyxel Omni.net Lcd+M Only)

    LCD+M. Internal Fax/Modem Basics The ZyXEL omni.net LCD+M contains a built-in 56K modem that can communicate with other analog modem through an ISDN line. What’s more, users can send and receive faxes by applying popular compatible fax packages such as WinFax or Microsoft Fax.

  • Page 110: Mnp Protocols

    Technical Reference for ZyXEL omni.net series Standard Speed (bps) V.21 V.22 1200 V.22 bis 2400 or 1200 V.32 9600 or 4800 V.32 bis 14400, 12000, 7200 V.34 33600 – 2400 V.90 56000 – 28000 Table 55. Modem Standards and Speeds MNP Protocols MNP (Microcom Network Protocol) is a set of protocols first introduced by Microcom, Inc., and alter used by many modem manufacturers.

  • Page 111: Fax And Facsimile

    Fax and Facsimile Fax is the abbreviation for facsimile. There are four major parts in a normal facsimile machine, the scanner, encoding and decoding device, modem, and printer. Before a page can be sent, it is first scanned, the bit-mapped data is encoded with data compression, and then it is transmitted across the phone line by an internal modem module.

  • Page 112: Dialing Out For Internal Fax/Modem

    Technical Reference for ZyXEL omni.net series Dialing Out for Internal Fax/Modem Using the “M” command following the “ATD” will tell your omni.net LCD+M to automatically switch calls to the internal fax/modem once dialing is complete. Type: ATDM17146930762<enter> Manually Switching Communication Modes The manual switching functions will only be necessary if your communication software does not allow you to change your dial-up string.

  • Page 113: Incoming Calls For Internal Fax/Modem

    character before completion of the handshake. If +FCLASS=1 is selected, the modem will behave as a facsimile modem and attempt to connect to a facsimile machine. This command will be aborted upon receipt of any DTE character if the modem has not finished dialing. In this case, the modem will go on-hook and return to command mode after displaying the NO CARRIER message.

  • Page 114: Lcd Panel When Internal Fax/Modem Operation

    Technical Reference for ZyXEL omni.net series When AT&L1 is set, an incoming analog call to phone2 will also report a ‘RING’ message to the DTE. You can answer an incoming analog call to the internal fax/modem by the command ‘ATA’. If the register S1 is not zero, the internal modem will automatically answer an incoming analog call when the Ring counter reaches the register S1 value.

  • Page 115: Control Data Compression

    Table 59. Control Data Compression AT Command Fax Operation The ZyXEL omni.net LCD+M supports the Group 3 sending and receiving facsimile function. You must connect the modem to a computer, usually a PC. The computer is the input/output device for the fax function.

  • Page 116: Fax Command Sets

    (ATDMs), fax command sets (EIA Class 1 fax commands), etc. The omni.net LCD+M internal modem supports Class 1 command set for the fax function. The Class 1 protocol uses the modem to transmit the fax data only. The connected computer handles the complete organizational overhead for this protocol.
  • Page 117 [S24b4-5] ATMn (n=0-3, default: 1): [S21b1-2] ATM0: Speaker always OFF ATM1: Speaker ON until carrier is detected. ATM2: Speaker always ON. ATM3: Speaker ON after the last digit is dialed AT&Kn (n=0-3, default: 1) [S27b0-1] AT&K0 Disables data compression. AT&K1 Automatic data compression (Default.) AT&K2 Enables MNP 5 data compression.
  • Page 118 Technical Reference for ZyXEL omni.net series (For more information on AT Command Set Reference, please refer to Appendix A, and for the information on Additional Result Code Table for Internal Fax/Modem please refer to Appendix D) 9-10...
  • Page 119 Part VI Diagnostics & Firmware Update...

  • Page 121: Chapter 10 Diagnostics

    The omni.net can perform its own diagnostic tests, providing you with valuable information. This chapter presents diagnostic tables for interpreting test results. The following table summarizes of the omni.net self-test sequence: Test Sequence Memory test ISDN chip interface test ISDN chip functional test HDLC functional test Note: * The LED lights up while test is in progress and blinks if a test fails.

  • Page 122: Power-On Self-Test

    Technical Reference for ZyXEL omni.net series Power-on Self-test At each power-up or after reset command from the panel, the omni.net will test the ROM code checksum, system RAM memory, EEPROM, digital circuits and analog circuit calibrations. The LNK LED will light up for half a second to indicate the success of the TA's power on self-test. After completing a successful self-test, the LNK LED will become the normal physical layer (layer 1) active indicator.

  • Page 123: Technical Reference For Zyxel Omni.net Series

    Type: AT&ZOI=[your_isdn_number]<Enter> omni.net responds: OK Type: AT&T11<Enter> omni.net responds: OK Dial [your_isdn_number] Loop from B1 to B2 through the switch established! Sending and receiving data... B1/B2 loopback test succeeded. Disconnecting... NO CARRIER The Diagnostic Command (ATCG) The [ATCG] command can be used to test and isolate hardware problems. Some of the tests are interactive, please follow the instructions on your screen.

  • Page 124: Resetting Your Omni.net

    Technical Reference for ZyXEL omni.net series Listen to the dial tone and then dial 1234567890*# 1234567890*# Dialed digits detected, please hang-up the handset ..!! On-hook action is detected, (Hook Interrupt) ... OK Resetting Your omni.net If you have modified the setting and cannot get your ISDN back on-line (the unit is locking up), you need to reset your omni.net.

  • Page 125: Capturing The Protocol Data

    D-channel and DTE-DCE interface. The EPA is designed for hobbyists as well as users with technical backgrounds. The EPA enables you to examine messages exchanged between your ISDN TA and the Central Exchange office when making an ISDN call. You can review the packets sent or received through the B-channel (for X.75 or V.120) to or from the remote site.

  • Page 126: Analyzing The Captured Data

    Technical Reference for ZyXEL omni.net series used with the ZyXEL CAPI driver. The ZyXEL CAPI driver communicates with the ISDN TA through this internal interface. It is not recommended that users get involved in this internal interface. The AT commands/responses, on the other hand, are in a standard user interface. An analysis of these commands and responses might prove very informative.
  • Page 127 commands are summarized as follows: EPA-Analyze AT Commands ATCT Clears buffer and starts the embedded protocol analyzer. Captures data immediately and starts the timer. ATC$ Invokes the interpretation function of the embedded protocol analyzer and displays the results on the DTE screen. Table 65.

  • Page 129: Firmware Upgrade

    This chapter describes how to upgrade the flash EPROM firmware of your omni.net when a new version is available. Upgrading with Flash EPROM Your omni.net ISDN TA employs a flash EEPROM (Electronic Erasable Programmable Read Only Memory) that lets you conveniently update firmware and program the ISDN TA with new features and enhanced functions.

  • Page 130: Kernel Mode

    Technical Reference for ZyXEL omni.net series NOTE: The American firmware version supports both the S/T interface and U interface models. During the power-on test, it checks the hardware configuration and follows the initialization procedures of the specific interface. Follow these steps to upgrade you omni.net with flash EPROM, by using a communications program: Step 1.
  • Page 131 Technical Reference for ZyXEL omni.net series 3 of the flash upgrading procedure outlined above. 11-3...

  • Page 133: Part Vii Appendices

    Part VII Appendices...

  • Page 135: At Command Set Reference

    Operation Modes of the DTE Interface There are two operation modes for the DTE interface: Simplex mode - used for conventional AT Command operation. Multiplex mode - used as an internal interface for ZyXEL CAPI drivers. Simplex mode In simplex mode, the omni.net is used just like an ordinary ISDN TA. The DTE interface will be either in command state or in data state.

  • Page 136: At Commands Description

    Technical Reference for ZyXEL omni.net series The commands or data are packaged. Each packet has its own destination address. All the DTE channels can be accessed individually by way of multiplexing. AT Commands Description An AT Command is a command in asynchronous data format issued by the computer to the ISDN TA through the asynchronous computer-modem interface.

  • Page 137: Basic 'At' Command Set

    Basic 'AT' Command Set AT Com. Options Re-execute the last command once A> Re-execute the last command once or repeat the last call up to 9 times. (See also S8) <any key> Terminate current connection attempt when enter in handshaking state.
  • Page 138 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix AT Com. Options PPP async-to-sync conversion. SLIP to sync HDLC conversion Multi Auto Dial Out (valid only if S80.6=1) Eurofile Transfer PPP+X.75 PPP+X.75+T.70+ISO_8208+T.90+BTX X.75+T.70+ISO_8208+T.90+BTX+PPP PPP+V.120 V.120+PPP PPP+X.75+V.120 PPP+V.120+X.75 X.75+V.120+PPP...
  • Page 139 All the Following Commands Require a 'AT' Prefix AT Com. Options CF(transfer_no.) For USA NI-1 & DMS-100 switch, activate the call forwarding variable function from the switch. (Note: You should issue AT&ZF4=n first, where n=IOC of CFV) For USA NI-I & DMS-100 switch, deactivate the call forwarding variable.
  • Page 140 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix AT Com. Options n=0-3 Suspend a call, 'n' is the call identifier (DSS1). (0 *) Clear buffer and start the embedded protocol analyzer. Capture data immediately and start timer. Invoke the interpretation function of the embedded protocol analyzer and display the results on DTE.
  • Page 141 All the Following Commands Require a 'AT' Prefix AT Com. Options Dial 's' (number and options) that follows for ISDN data call. Repeat last ATD command. Dial ‘s’ (number and options) that follows for the internal fax/modem (LCD+M only) n=0-1 Set the Directory Numbers (USA.) DN0=xxx Set the DN0 value.
  • Page 142 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix AT Com. Options Display Microsoft PnP code. Display PPP status. n=0-255 Add-threshold for PPP/MP Bandwidth-On-Demand (48 *) in Kbps unit n=0-255 Sub-threshold for PPP/MP Bandwidth-On-Demand (32 *) in Kbps unit KAxn n=0-63...
  • Page 143 All the Following Commands Require a 'AT' Prefix AT Com. Options AT&T custom point-to-point AT&T custom point-to-multipoint (1 SPID) AT&T custom point-to-multipoint (2 SPID) n=0-2 Result code displayed Q0 (*) omni.net returns result code. omni.net does not return result code. omni.net returns result code but quiet after answering on a RING.

  • Page 144: Description Of Ati3 Output

    Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix AT Com. Options (0.001 *65) save the charging fee per unit to NVRAM. UNIT=xxx UNIT? View the value of charging fee per unit. Upload firmware to the Flash EPROM. Verbal/Numeric result codes.
  • Page 145 HDLC Transmit Under-run : 0 Refer to the following table for a description of the Output Parameters of the Link Status Report. Link Status Report (ATI3) Output Parameters Output Parameter Connect DTE Speed Current on-line DTE speed. Error Control Level Error control protocol used for current session.

  • Page 146: Extended 'At&' Command Set

    Technical Reference for ZyXEL omni.net series Extended 'AT&' Command Set All the Following Commands Require a 'AT' Prefix AT Com. Options &Cn Carrier Detect (CD) options &C0 CD always ON (See also S42b7). &C1 (*) CD tracks presence of carrier (See also S38b3). &Dn Data Terminal Ready (DTR) options.
  • Page 147 All the Following Commands Require a 'AT' Prefix AT Com. Options &Kn &K0 Disables data compression &K1 Automatic data compression (Default.) &K2 Enables MNP 5 data compression &K3 Enables V.42 bis data compression. &Knn PPP/V.120/X.75 data compression control. &K must be followed by two digits. &K00 Disable V.42bis.
  • Page 148 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix AT Com. Options &V1-4 View the (n-1)th user profile settings (n=1-4). &V5 View factory-set default settings. &V6 View POTS port, Phone 1 setting. &V7 View POTS port, Phone 2 setting. &Wn n=0-3 Write current settings to user profile 'n' in NVRAM.
  • Page 149 All the Following Commands Require a 'AT' Prefix AT Com. Options &ZF3=s Assign the IOC for Message Waiting. &ZF4=s Assign the IOC for Call Forwarding. &ZF? Show the setting of 'AT&ZFn=s' &ZOx=s Write own phone number (including sub-address, if any). The number specified by '&ZOx' will be used as the calling party number while dialing.

  • Page 150: Extended 'At*' Command Set

    Technical Reference for ZyXEL omni.net series Extended 'AT*' Command Set All the Following Commands Require a 'AT' Prefix AT Com. Options Character length, including start, stop and parity bit. *C0 (*) DTE port 10-bit character length. n=0-39 Set default dial pointer at telephone directory location 'n'. *D0 (*) (See also S35b4 and S38b0) Security function selection.

  • Page 151: Fax Command

    Fax Command All the Following Commands Require a 'AT' Prefix AT Com. Value +FCLASS=n Service class selection Sets to modem mode. Sets to Class 1 mode +FTS=n 0-255 Stops transmission and pauses, in 10ms units. +FRS=n 0-255 Waits for silence, in 10ms units. +FTM=<MOD>...

  • Page 153: Status Registers & Result Codes

    Technical Reference for ZyXEL omni.net series Appendix B Status Registers & Result Codes S-registers (Status Registers) contain values that determine and reflect how your omni.net Terminal Adapter (TA) operates and executes commands. You can read the values and change them, using either terminal commands or the TA's panel controls with the same results.

  • Page 154: Setting S-Registers

    Technical Reference for ZyXEL omni.net series To view all of the S-register settings use the '&Vn' AT command: AT&Vn The following table summarizes the S-register viewing commands. S-register Viewing AT Commands ATSr r=0-124 Display the value stored in S-register 'r'. AT&Vn n=0-7 View all of the S-register settings.
  • Page 155 bits in the S-register simultaneously, the second command lets you change bit 'm' without affecting other bits in this S-register. When using ATSr=n, you need to do a conversion to or from the binary number to find out which bits you manipulate. For example, if you want to set S38 bit 3 to 1 for a specific application, you may either use the straight-forward command ATS38b3=1 or use the following ATS38=n command, as explained in the following example:...

  • Page 156: S-Register Descriptions

    Technical Reference for ZyXEL omni.net series To set bit 3 to 0 (binary), you must invert the value using a logic NOT operation and then do a logic AND operation. Operation Example-1 Binary Dec. 00001000 11110111 10001000 10000000 Finally, using the result decimal value 'n', issue an ATS38=n to set the register S38 to the new desired value.

  • Page 157: Basic S-Registers 'Atsn=X

    Basic S-Registers 'ATSn=x' All the Following Commands Require a 'AT' Prefix S Com. Set the number of rings on which the omni.net will answer. A '0' value disables auto-answer. Counts and stores number of rings from an incoming call. Define escape code character, default <+> (43 dec.). Define ASCII Carriage Return.

  • Page 158: Extended S-Registers "Atsn=X

    Technical Reference for ZyXEL omni.net series Extended S-Registers "ATSn=x" All the Following Commands Require a 'AT' Prefix S Com. Function and description S14= Bit mapped register omni.net auto-handshake mode on originate mode. omni.net auto-handshake mode on answer mode. S15= Bit mapped register Even parity 2 (*) No parity...
  • Page 159 2400 bps 1200 bps 460800 bps S21= Bit mapped register For omni.net LCD+M only. DSR always On. According to CCITT (see also S44b4, S41b5). CD always On. CD tracks presence of data connection (see also S38b3). CTS follows RTS, in synchronous mode.
  • Page 160 The setting of S21(b1-2) will be affected to Phone 2 keypad-dial. POTS Port tone volume low. POTS Port tone volume high. S27= Bit mapped register Modem data compress (for omni.net LCD+M only) DTE port Flow Control disabled. DTE port Hardware (RTS/CTS) flow control. Reserved. 28 X5 30 X6 38 X7 +Def./Ref.
  • Page 161 All the Following Commands Require a 'AT' Prefix S Com. Function and description S29= 0-39 0-39 Set default dial phone number pointer, use 'AT&Zn=s' to store phone numbers. S31= 0-25 0-FF Holds the ASCII decimal value of the XON. S32= 0-25 0-FF Holds the ASCII decimal value of the XOFF.
  • Page 162 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix S Com. Function and description S41= Bit mapped register Enable CCITT signals 140 and 141 on EIA-232D interface. DSR follows DCD and pulses (see S44b4). Force S0>=2. S42= Bit mapped register Disable escape sequence code in answer mode.
  • Page 163 All the Following Commands Require a 'AT' Prefix S Com. Function and description Can NOT get busy tone from Phone 1. Can get busy tone from Phone 2. Can NOT get busy tone from Phone 2. 0 (*) Disable the 'RING' message to DTE port for analog call. Enable the 'RING' message to DTE port for analog call.
  • Page 164 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix S Com. Function and description Sending Low Layer Compatibility information for ISDN data call. 0 (*) Not send Low Layer Compatibility information for POTS port Sending Low Layer Compatibility information for POTS port S82= ISDN B-channel protocol.
  • Page 165 All the Following Commands Require a 'AT' Prefix S Com. Function and description S84= Embedded Protocol Analyzer control. Capture DTE-DCE interface protocol information. Capture B-channel (X.75 or V.120) frames. Capture D-channel protocol information. 0 (*) Display S register value in decimal format. Display S register value in hex format.
  • Page 166 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix S Com. Function and description Bundle connection is enabled in answer mode only. Bundle connection is enabled in call mode only. Bundle connection is enabled in both directions. S89= Bundle and data encryption control.
  • Page 167 All the Following Commands Require a 'AT' Prefix S Com. Function and description SI=2 Fax Gruppe 3 3 (*) Daten Ober Modem Btx Ober Modem SI=7 Daten bertragung 64 Kbps (X.75 SLP) 11------ Async. V.110 01------ Extensions of async. --0----- Number of data bits: 8 --1----- Number of data bits: 7...
  • Page 168 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix S Com. Function and description 10101111 In band negotiation S108+n= High Layer Compatibility (Non-1TR6) n=1, POTS port, Phone 2 n=2, ISDN data n=3, POTS port, Phone 1 0 (*) No High-Layer-Compatibility information element will be sent.
  • Page 169 All the Following Commands Require a 'AT' Prefix S Com. Function and description Use Speech Bearer service whenever possible for POTS port, Phone 2. 0 (*) Use 3.1KHz Bearer service whenever possible for POTS port, Phone 1. Use Speech Bearer service whenever possible for POTS port, Phone 1.
  • Page 170 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix S Com. Function and description 0 (*) Enable normal MSN function Treat the number assigned by '&ZI=n...' as sub-address, and match with the called_party_subaddress for inbound call routing.
  • Page 171 All the Following Commands Require a 'AT' Prefix S Com. Function and description Programmable ring frequency, using following value to choose ring frequency: 0 (*) 50Hz 40Hz 25Hz 20Hz 0 (*) D-channel L2 send DISC actively. D-channel L2 doesn't sent DISC. 2-3, 5-7 Reserved.
  • Page 172 Technical Reference for ZyXEL omni.net series All the Following Commands Require a 'AT' Prefix S Com. Function and description Reserved. S123= Select Caller ID signaling method. 0 (*) Country default. DTMF, prior to ring. ETS FSK, during ring. ETSI FSK, prior to ring. Reserved S124= Empty IP packet interval for PPP...

  • Page 173: Atxn' Result Code Option Table

    'ATXn' Result Code Option Table The following table shows the different options available when setting the 'ATXn' command. The default value for 'n' is 5 when the omni.net is shipped: ATV0 ATV1 ATX0 CONNECT RING NO CARRIER ERROR CONNECT 1200 NO DIAL TONE BUSY NO ANSWER...
  • Page 174 Technical Reference for ZyXEL omni.net series ATV0 ATV1 ATX0 CONNECT 102400 CONNECT 61440 CONNECT 51200 CONNECT 62400 CONNECT 124800 CONNECT 62400 CONNECT 41600 CONNECT 31200 CONNECT 249600 CONNECT 20800 CONNECT 33600 CONNECT 28800 CONNECT 26400 CONNECT 24000 CONNECT 21600 CONNECT 48000 CONNECT 56000 CONNECT 64000 CONNECT 112000...

  • Page 175: Result Code For Internal Fax/Modem (For Zyxel Omni.net Lcd+M Only

    Result Code for Internal Fax/Modem (for ZyXEL omni.net LCD+M only) The internal fax/modem will report the connect speed in the following format: ATX1-ATX4(%): <cr><lf>CONNECT DTE_Speed<cr><lf> ATX5(^): <cr><lf>CONNECT DTE_Speed/Modem DCE_Speed/Data Compression<cr><lf> example: CONNECT 115200/Modem 33600/V42b ATX6 : <cr><lf>CONNECT DCE_Speed[/Error_Code]<cr><lf> example: CONNECT 33600/ARQ ATX7(&):...
  • Page 176 Technical Reference for ZyXEL omni.net series CONNECT 41333 CONNECT 42666 CONNECT 44000 CONNECT 45333 CONNECT 46666 CONNECT 48000 CONNECT 49333 CONNECT 50666 CONNECT 52000 CONNECT 53333 CONNECT 54666 CONNECT 56000 Table 76. Additional Result Codes B-24 & & & & &...

  • Page 177: Result Code Chart Symbol Reference

    Result Code Chart Symbol Reference Supported Reporting the DTE rate as: <cr><lf>CONNECT DTE_Speed<cr><lf> <cr><lf>CONNECT DTE_Speed/Protocol[DCE_Speed/Error_Control[/Data_Compression]]<cr><lf> <cr><lf>CONNECT DCE_Speed[/Error_Code]<cr><lf> Example: CONNECT 64000/ARQ <cr><lf>CONNECT DCE_Speed/Error_Code/Protocol[/Error_Control[/Data_Compression]]<cr><lf> <cr><lf>CONNECT DTE_Speed/Modem DCE_Speed/Data_Compression<cr><lf> <cr><lf>CONNECT DTE_Speed/Data_Compression<cr><lf> & <cr><lf>CARRIER DCE_Speed<cr><lf> <cr><lf>PROTOCOL: Protocol<cr><lf> <cr><lf>ERROR CONTROL: Error_Control<cr><lf> [<cr><lf>COMPRESSION: Data_Compression<cr><lf>] <cr><lf>CONNECT DTE_Speed<cr><lf> Table 77. Result Code Chart Symbol Reference Technical Reference for ZyXEL omni.net series B-25...

  • Page 178: Result Code Field Descriptions

    Technical Reference for ZyXEL omni.net series Result Code Field Descriptions Field Name Error_Code NONE Error_Control LAPB, LAPD, ARQ (This field will not show if no error control is negotiated) Data_Compression V42b (for ISDN data connection) V42b, MNP5, or NONE (for modem connection) DTE_Speed All possible DTE speeds supported.

  • Page 179: Connect Strings For Error Corrected Connections

    Connect Strings for Error Corrected Connections Use 'ATS35' bit 7 ('ATS35b7=1') to enable the following numerical result codes when an error control connection is made. ATV0 Code ATV1 String CONNECT CONNECT 1200 CONNECT 2400 CONNECT 4800 CONNECT 7200 CONNECT 9600 CONNECT 12000 CONNECT 14400 CONNECT 16800...

  • Page 181: Phone Jack Pinout Assignments

    Phone Jack Pinout Assignments The omni.net LCD/Plus/D features one RJ-45 phone jack, and in addition, the omni.net LCD/Plus has two RJ-11 phone jacks. The RJ-45 jack labeled "ISDN S' is used for ISDN line connection (S/T interface) The RJ-11 jacks labeled "PHONE 1" and "Phone 2" (also known as an analog adapter or POTS port in European countries) provide for an optional connection to analog telephone equipment such as telephone set, answering machine, fax machine or analog modem.

  • Page 182: Pots Port Phone 1&2 (For Omni.net Lcd/Lcd+M/Plus

    Technical Reference for ZyXEL omni.net series RJ-11 POTS Port Phone 1&2 (for omni.net LCD/LCD+M/Plus) RJ-11 Connector Pin Assignment Not Connected Ring Not Connected Table 81. RJ-11 Connector Pin Assignment Description...

  • Page 183: Serial Port Interface

    EIA-232D 25 Pin Serial Port Interface ITU-TSS Pin # Signal Description Name Clock Source: Sync RX Clock LA/LBK 108/2 108/1 RD/LBK Technical Reference for ZyXEL omni.net series Serial Port Interface Signal Description Signal Name Protective Ground Transmitted Data Received Data Request To Send Clear To Send Data Set Ready...
  • Page 184 Technical Reference for ZyXEL omni.net series ITU-TSS Pin # Signal Description Name Clock Source: Table 82. EIA-232D 25 Pin Serial Port Interface Async. Hardware Flow Control Cable Connection Modem to PC (DTE) (DCE) Signal DB 9 DB25 Ground CD (DCD) Table 83.
