4 Application (intended use)

The EC-Fire switchgear is used for the pressure-
dependent and volume-flow dependent control
of up to 3 constant speed pumps in fire extin-
guishing systems. Signal detection occurs by
means of pressure switch, pressure sensor, flow
switch or volume flow sensor.
Intended use also means compliance with this
manual. Any other use is regarded as
non-compliant with the intended use.

5.2.1 Switchgear

Mains connection:
Max. current consumption:
Activation type:
Ambient/operating temperature:
Storage temperature:
Max. relative humidity:
Protection class:
Control voltage:
Housing material:
Electrical safety:

5.2.2 Inputs

• 1x analogue input 4 – 20 mA for the
pressure sensor
• 1x analogue input 4 – 20 mA for the volume
flow sensor
• 1x digital input for the pressure switch
• 1x digital input for the flow switch
• 1x digital input for the protection against low
water level
• 1x digital input for remote switch-off of all
pumps (Ext. Off)

5.2.3 Outputs

• 1x potential-free changeover contact for SSM
• 1x potential-free changeover contact for SBM
• 1x potential-free normally closed contact for ESM
per pump
• 1x potential-free normally open contact for EBM
per pump
• 1x output 24 V DC (max. 4 VA) for connection of a
signal lamp etc.
• 1x analogue output 0 – 10 V for display of the
actual pressure value
Installation and operating instructions Wilo-Control EC-Fire

5 Product information

5.1 Type key

Example: W-CTRL-EC-F-2x12A-T34-DOL-CPI-WM
W W = WILO
CTRL Switchgear
EC EC = Easy Control switchgear for
fixed-speed pumps
F Control for fire-extinguishing system
2x Max. number of pumps that can be
connected
12A Max. rated current in ampere per pump
T34 Mains connection:
T = three-phase current (3~)
34 = live wire, e.g. 380 – 400 V
DOL Direct activation of the pump(s)
CPI Insulation monitoring device(s) installed
for pumps in the switchgear
WM Wall fixation

5.2 Technical data

See rating plate
See rating plate
Direct
0...+40 °C
-30...+60 °C
90 %, non-condensing
IP54
See rating plate
Depending on version:
Polycarbonate, UV-resistant
Steel sheeting, powder coated
Pollution degree II

5.3 Scope of delivery

• Switchgear
• Installation and operating instructions
• Circuit diagram (for devices in a metal
housing only)

5.4 Accessories and options

5.4.1 Accessories

• Float switch for dry-running protection
• Pressure switch for dry-running protection
• Pressure switch for pump control
• Pressure sensor for pump control
• Volume flow sensor for pump control
• Rotating beacon 24 V DC
NOTICE
In the event that the EC-Fire switchgear is
delivered in a Wilo system, the accessories may
already be fitted.
