OSD Menu

Use the On-Screen-Display Menus shown below to adjust the projected image. To access and
adjust the On-Screen-Menu do the following:
1. Press the Menu button on the remote control to select one of six on-screen menus: Main
Menu, Setup Menu, Color Manager Menu, Language Menu, Utility Menu, and Status
Menu.
2. Press arrow keys Left / Right ( / ) for main menu selection, and use arrow keys
upward / downward ( /
3. Press the "menu" button to exit an OSD menu.

Main Menu

PC Mode
Contrast
Brightness
Horizontal
Position
Vertical Position
Reset
) for sub-menu or for adjustment selection.
Use arrow keys Left / Right ( / ) to adjust the contrast.
Adjustment range: from min-max (0 – 100) by 50 steps.
(Default value: factory calibrated)
Use arrow keys Left / Right ( / ) to adjust the brightness.
Adjustment range: from dark – light (0-100) by 50 steps.
(Default value: factory calibrated)
Use arrow keys Left / Right ( / ) to adjust the position in
horizontal direction.
Adjustment range: from left – right (0-100).
(Default value: centre position)
Use arrow keys Left / Right ( / ) to adjust the position in vertical
direction.
Adjustment range: from bottom – top (0-100).
(Default value: centre position)
Use ↵ button to reset to default value.
In PC mode to reset contrast, brightness to default value.
In Video mode to reset contrast, brightness to default value.
DLP
Digital Projector User's Guide
Video Mode
21
