Installation Steps

Getting Started

1. Place the projector on a flat surface.
2. Position the projector at the desired distance from the screen.
3. The projection distance is less than 33 feet (10M).
CAUTION:
•
Proper ventilation is import. Don't block ventilation openings. Never operate this
projector in an enclosed area. Do not place the projector on a tablecloth or other
soft covering that may block the vents. With ceiling installations, use approved
mounting hardware. Do not put the projector near heater, air ducts, transformers or
other electrical devices. For permanent installations follow local codes.
•
Don't set liquids on the projector. Spilled liquids may damage your projector.
•
Don't put the projector on a hot surface or in direct sunlight.
•
Do not drop the projector.

Connecting the Projector

1. Connect the power cable
2. When you connect the power cable to the projector, the Power LED & Lamp Ready
LED on the control pad will illuminate, wait until LED stop flashing before turning on
the projector.
Power outlet
Lights in green
(Standby)
Audio input
AC IN Socket S-Video input
Composite
Video input
™
DLP Digital Projector User's Guide
DVI input port
(connects to computer, HDTV,
and Component video player)
USB Connector
(connects to PC mouse port so
Remote Control can be used as
a mouse control only)
13
