OSD Menu Controls

The projector has an OSD that lets you make image adjustments and change various settings.

Navigating the OSD

You can use the remote control cursor buttons or the buttons on the top of the projector to navigate
and make changes to the OSD. The following illustration shows the corresponding buttons on the
remote control and on the projector.
5
4
3
1. To open the OSD, press the Menu button.
2. There are six menus. Press the cursor
button to move through the menus.
3. Press the cursor
down in a menu.
4. Press to change values for settings, and
then press Enter or
setting.
5. Press Menu to close the OSD or leave a
submenu.
Note:
Depending on the video source not all items in the OSD are available. For example, the
Horizontal/Vertical Position items in the Setup menu can only be modified when connected to a
PC. Items that are not available cannot be accessed and are grayed out.
O -S
N CREEN
button to move up and
to confirm the new
D (OSD) M
ISPLAY
4
1
2
SOURCE
– 15 –
S
ENU ETTINGS
3 5 2 1
KEYS TONE
AUTO
M ENU
KEYS TONE
POWER
