Adjusting the Keystone Control

Adjusting the Zoom and Pan

ZOOM
Original size
□ Make any necessary image adjustments by using the on-screen menus.
(Refer page OSD Menu section for the details)
To adjust image vertically and make a square
image. Adjust the keystone function by pressing
the keystone button on the remote control or
through OSD menus.
Press the zoom +/- buttons on remote control to
enter zoom mode, and use directional keys to pan
upward, downward, right, and left.
Four times as large
as the original size
™
DLP Digital Projector User's Guide
17
