DLP Digital Projector User's Guide
The following buttons are located on the projector Control Pad
or on the Remote Control
Power Button
Menu Button
Auto Button
Source Button
Status Button
L Button
R Button
↵ Button
4 Directional
Selection Buttons
Laser Pointer Button
Volume +/– Button
Keystone Button
Blank Button
Freeze Button
Mute Button
Zoom Button
Input Source
Selection
12
Switch power on or off.
Use the Power button to begin the warm-up period. The power
light blinks green during warm-up and stays green when the
projector is ready to use.
Use to display the On-Screen-Display Menus, which provide
several options for adjusting the projected image.
Use to auto adjust the image quality.
Use to select input source.
Use to get projector's operation status information
Use as the left mouse button.
Use as the right mouse button.
Press to enter function.
Use to select or adjust the control items
Use instead of a pointer to activate the laser pointer for use in
presentations.
Use to adjust the volume of the audio output.
Use to adjust the image vertically and make it square.
Use to blank the image and mute audio.
Use to freeze or unfreeze the image
Use to turn on or off the speaker.
Use the Zoom (+/-) buttons to zoom the image in and out. Use
the 4 directional selection buttons to pan the image.
To select the correct device you are connecting with.
