Timing Charts
The projector can display several resolutions. The following table outlines the resolutions
that can be displayed by the projector.
Table 2: ANALOG Computer Timings (Resolution and Refresh Rate【fV】)
Resolution
640 x 350
640 x 480
640 x 480
640 x 480
640 x 480
720 x 400
720 x 400
800 x 600
800 x 600
800 x 600
800 x 600
1024 x 768
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
640 x 480
832 x 624
1280 x 1024
Table 3: DIGITAL Computer Timings (Resolution and Refresh Rate 【fV】
Resolution
640 x 350
640 x 480
640 x 480
640 x 480
640 x 480
720 x 400
720 x 400
800 x 600
800 x 600
800 x 600
800 x 600
1024 x 768
1024 x 768
1024 x 768
1280 x 1024
640 x 480
832 x 624
1280 x 1024
30
FH(kHz)
FV (Hz)
37.9
85
31.5
60
37.9
72
37.5
75
43.3
85
31.5
70
37.9
85
37.9
60
48.1
72
46.9
75
53.7
85
35.5
43.4
56.5
70
68.7
85
64.0
60
79.98
75
35.0
66.68
49.73
74.55
64.0
60
FH(kHz)
FV (Hz)
37.9
85
31.5
60
37.9
72
37.5
75
43.3
85
31.5
70
37.9
85
37.9
60
48.1
72
46.9
75
53.7
85
35.5
43.4
56.5
70
68.7
85
64.0
60
35.0
66.68
49.73
74.55
64.0
60
Signal mode
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded SVGA
Expanded SVGA
Expanded SVGA
Expanded SVGA
Native XGA
Native XGA
Native XGA
Compressed SXGA
Compressed SXGA
Expanded Mac II 13"
Expanded Mac 16"
Compressed FM Town
Signal mode
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded VGA
Expanded SVGA
Expanded SVGA
Expanded SVGA
Expanded SVGA
Native XGA
Native XGA
Native XGA
Compressed SXGA
Expanded Mac II 13"
Expanded Mac 16"
Compressed FM Town
