- Page 1 pottery barn kids FARMHOUSE KITCHEN FRIDGE Date: 8‐Aug‐13 www. potterybarnkids.com ...
- Page 2 The use of power tools to aid in assembly is not recommended. Power tools can damage hardware and split wood. The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions. It may take 1 hour or more to assembly your Farmhouse Kitchen Fridge. Parts Included: Top Panel Left Side Panel...
- Page 3 Hardware Included: Door Catch Female Door Catch Male Flat Washer Spring Washer Screw 10mm Screw Screw Screw Bolt Bolt 12mm 15mm 25mm Dia. 1/4” x 1” Dia.
- Page 4 1. Attach Legs (H and I) to Bottom Panel (D) using the Bolt (T), Spring Washer (N) and Flat Washer (M). Loosely tighten the bolts, and then tighten with Allen Key. Dia. 1/4” x 1-1/2” Arrow to Front 2.
- Page 5 3. Attach the Right Side Panel (C) to Shelves (E) using the Bolt (S), Spring Washer (N) and Flat Washer (M). Loosely tighten the bolts, and then tighten with Allen Key. Dia. 1/4” x 1” ...
- Page 6 5. Slide Back Panel (F) into grooves on Side Panels (B and C) and Bottom (D) as shown below. Wood block at back top 6. Align the holes on Back Panel (F) with the pre-drilled holes on Shelves (E) , insert Screws (R) and tighten with Phillips Head Screwdriver.
- Page 7 7. Attach Top Panel (A) to the Side Panels (B and C) using Bolt (S), Spring Washer (N) and Flat Washer (M). Loosely tighten the bolts, and then tighten with Allen Key. Dia. 1/4” x 1” 8. Attach Door (G) to Left Side Panel (B) using Screws (P) with Phillips Head Screwdriver. Attach Door Catch Male (L) to Door (G) using Screws (O) with Phillips Head Screwdriver.
- Page 8 9. Attach Door Catch Female (K) to Right Side Panel (C) using Screws (O) with Phillips Head Screwdriver. Attach Handle (J) to Door (G) using Screws (Q) with Phillips Head Screwdriver. 15mm 10mm 10. Close the door and check if the door catches (L and K) can be matched very well. If not, slightly loose the screws of the door catch female, adjust it to be matched with door as shown, and then tighten up the screws.
- Page 9 Adjusting the levelers: Due to an uneven floor, the furniture may not sit level due causing it to wobble. If the furniture wobbles, determine which corner does not touch the ground correctly. With two people follow these steps: 1. Carefully elevate the item slightly to provide access to the levelers attached to the bottom. 2.
- Page 10 FURNITURE TIPPING RESTRAINT WARNING: This product is only a deterrent. It is not a substitute for proper adult supervision. Manufacturer assumes no liability for improper installation or excessive loads placed on screws, brackets or straps. Young children may be injured by tipping furniture and the use of a tipping restraint is highly recommended. When properly installed, this restraint will provide protection against tipping of furniture.
