Summary of Contents for pottery barn kids OWEN
- Page 1 OWEN LOFT BED www.potterybarnkids.com Date: 2016-Jan.-23 Rev: Page 1 of 7...
- Page 2 • DO NOT use loft bed if any parts are missing or broken. • DO NOT use substitute parts. Contact pottery barn kids for replacement parts and instructional literature if needed. • Follow the information on the warnings appearing on the upper loft end structure and on the carton.
- Page 3 Important Safety Instructions: • Please read all instructions carefully before assembling. • For your safety, assembly by two or more adults is strongly recommended. • Keep instructions for future use. • Use only vendor supplied hardware to assemble. Using unauthorized hardware could jeopardize the structural integrity of the item.
- Page 4 Assembly Instruction Steps: Attach (C) to (A) as shown below. Note: Do not fully tighten the bolts to make the next steps easier. Step 1-2 Step 1-1 2. Attach (D) to (A) as shown below. Note: Do not fully tighten the bolts to make the next steps easier. Step 2-2 Step 2-3 Step 2-1...
- Page 5 3. Attach (B) to (C) and (D) as shown below. Note: Do not fully tighten the bolts to make the next steps easier. Step 3-3 Step 3-2 Step 3-1 4. Carefully attach (E) to (A&B) by spreading (A& B) as shown below. Spread Spread Date: 2016-Jan.-23...
- Page 6 5. Secure (E) to (A&B) as shown. Do not fully tighten. Step 5-3 Step 5-1 Step 5-2 6. Check the alignments and fully tighten all bolts at this time. Do not over tighten. 7. Attach (G) onto (E). Secure the ladder with (M) using a Phillips head screwdriver (Not included). Make sure to use pre-drilled holes as guidance.
- Page 7 8. Check the alignments and fully tighten all bolts at this time. Do not over tighten. 9. Lay the slat roll (F) onto the support rails on the inner side of (D) and (E). Secure each slat by wood screw (L) at two ends using a Phillips head screwdriver (Not included). 10.
